Edelbrock Camshaft 2264

Authorized Dealer
Brand: Edelbrock Edelbrock
0 reviews
  • Have a product question? Ask us
  • Part Number: 2264
  • Part Location: U.S.
  • Availability: *Special Order
  • Delivery: Up to 2 Weeks
  • If purchased before 12:00 EDT - estimated delivery by July 17
Retail: $661.49
Price: $629.99
You Save: $31.50
Advertised Exhaust Duration (DEG)
315 Degree
Advertised Intake Duration (DEG)
308 Degree
Computer-Controlled Compatible
No
Engine Compatibility
Chevy Big Block V8 7.4L 454 Cubic Inch
Exhaust Duration At 0.050 Inch Lift (DEG)
256 Degree
Exhaust Valve Lift (IN)
0.648 Inch
Intake Centerline Angle (DEG)
248 Degree
Intake Duration At 0.050 Inch Lift (DEG)
248 Degree
Intake Valve Lift (IN)
0.632 Inch
Lobe Separation Angle (DEG)
112 Degree
Recommended Use
Street
Share this page

Edelbrock Camshaft

Camshaft; Rollin Thunder; Chevy Big Block 8.2L+/500+ Cubic Inch; Hydraulic Roller; 1500-6500 RPM Range; 248 Degree Intake/ 256 Degree Exhaust Duration @ 0.050 Inch Lift; 0.632 Inch Intake/ 0.648 Inch Exhaust Valve Lift; 112 Degree Lobe Separation Angle

MPN: 2264

Rollin thunder performer RPM cams feature more aggressive profiles than conventional cams without excessive valve overlap and provide power from 1500 to 6500 RPM. They are used in our 435 Horsepower and 440 Horsepower E-Tec crate engines, our 460 Horsepower signature series 383 crate engine and our 650 Horsepower and 675 Horsepower 555 crate engines. Roller tappets reduce friction, virtually eliminate Break-In problems, and permit higher valve velocities for increased performance. Intended for use with OEM or Edelbrock hydraulic roller tappets
Engine Compatibility: Chevy Big Block V8 7.4L 454 Cubic Inch
Recommended Use: Street
Type: Hydraulic Roller
RPM - Low: 1500
RPM - High: 6500
Intake Duration At 0.050 Inch Lift (DEG): 248 Degree
Exhaust Duration At 0.050 Inch Lift (DEG): 256 Degree
Advertised Intake Duration (DEG): 308 Degree
Advertised Exhaust Duration (DEG): 315 Degree
Intake Valve Lift (IN): 0.632 Inch
Exhaust Valve Lift (IN): 0.648 Inch
Lobe Separation Angle (DEG): 112 Degree
Intake Centerline Angle (DEG): 248 Degree
Computer-Controlled Compatible: No

Features

  • Rollin Thunder Performer RPM Cams Feature More Aggressive Profiles Than Conventional Cams Without Excessive Valve Overlap And Provide Power From 1500 To 6500 RPM
  • Roller Tappets Reduce Friction, Virtually Eliminate Break-In Problems And Permit Higher Valve Velocities For Increased Performance
  • Limited 1 Year Warranty
Specifications of Edelbrock Camshaft 2264
Advertised Exhaust Duration (DEG) 315 Degree
Advertised Intake Duration (DEG) 308 Degree
Computer-Controlled Compatible No
Engine Compatibility Chevy Big Block V8 7.4L 454 Cubic Inch
Exhaust Duration At 0.050 Inch Lift (DEG) 256 Degree
Exhaust Valve Lift (IN) 0.648 Inch
Intake Centerline Angle (DEG) 248 Degree
Intake Duration At 0.050 Inch Lift (DEG) 248 Degree
Intake Valve Lift (IN) 0.632 Inch
Lobe Separation Angle (DEG) 112 Degree
Recommended Use Street
RPM - High 6500
RPM - Low 1500
Type Hydraulic Roller
