Crane Camshaft 688531

Brand: Crane Engine Parts Manufacturer
0 reviews
  • Have a product question? Ask us
  • Part Number: 688531
  • Part Location: U.S.
  • Availability: *Special Order
  • Delivery: Up to 2 Weeks
  • If purchased before 12:00 EDT - estimated delivery by July 15
Retail: $621.59
Price: $591.99
You Save: $29.60
Advertised Exhaust Duration (DEG)
308 Degree
Advertised Intake Duration (DEG)
304 Degree
Computer-Controlled Compatible
No
Engine Compatibility
Chrysler V8 383-440 Cubic
Exhaust Duration At 0.050 Inch Lift (DEG)
258 Degree
Exhaust Valve Lift (IN)
0.561 Inch
Grind Number
R-254/420-2-10
Intake Centerline Angle (DEG)
107 Degree
Intake Duration At 0.050 Inch Lift (DEG)
254 Degree
Intake Valve Lift (IN)
0.561 Inch
Recommended Use
Performance
Share this page

Crane Camshaft

Camshaft; For Use With 1970-1978 Chrysler 383-440 Engines

MPN: 688531

Designed for operation at ranges that can exceed 10,000 RPM, mechanical roller cams represent the ultimate in efficiency. While a large number of mechanical roller cams are used in purely competition applications, Crane Cams does manufacture less severe roller grinds that are designed for high performance street engines that have higher compression or power-adders. For best results, valve lash must be checked and set periodically.
Engine Compatibility: Chrysler V8 383-440 Cubic
Recommended Use: Performance
Type: Mechanical Roller
RPM - Low: 3400
RPM - High: 7200
Intake Duration At 0.050 Inch Lift (DEG): 254 Degree
Exhaust Duration At 0.050 Inch Lift (DEG): 258 Degree
Advertised Intake Duration (DEG): 304 Degree
Advertised Exhaust Duration (DEG): 308 Degree
Intake Valve Lift (IN): 0.561 Inch
Exhaust Valve Lift (IN): 0.561 Inch
Intake Centerline Angle (DEG): 107 Degree
Grind Number: R-254/420-2-10
Computer-Controlled Compatible: No

Features

  • Designed For Operation At Ranges That Can Exceed 10,000 RPM, Mechanical Roller Cams Represent The Ultimate In Efficiency
  • Limited 1 Year Warranty For Street Use And No Warranty For Race Use
Specifications of Crane Camshaft 688531
Advertised Exhaust Duration (DEG) 308 Degree
Advertised Intake Duration (DEG) 304 Degree
Computer-Controlled Compatible No
Engine Compatibility Chrysler V8 383-440 Cubic
Exhaust Duration At 0.050 Inch Lift (DEG) 258 Degree
Exhaust Valve Lift (IN) 0.561 Inch
Grind Number R-254/420-2-10
Intake Centerline Angle (DEG) 107 Degree
Intake Duration At 0.050 Inch Lift (DEG) 254 Degree
Intake Valve Lift (IN) 0.561 Inch
Recommended Use Performance
RPM - High 7200
RPM - Low 3400
Type Mechanical Roller

1900 Chrysler 383/413/426W/440 RB
