COMP Cams Camshaft 5580210

Authorized Dealer
Brand: COMP Cams COMP Cams
0 reviews
  • Have a product question? Ask us
  • Part Number: 55-802-10
  • Part Location: U.S.
  • Availability: *Special Order
  • Delivery: Up to 2 Weeks
  • If purchased before 12:00 EDT - estimated delivery by July 21
Retail: $883.04
Price: $840.99
You Save: $42.05
Advertised Exhaust Duration (DEG)
RZ317 Degree
Advertised Intake Duration (DEG)
RX304 Degree
Computer-Controlled Compatible
No
Exhaust Duration At 0.050 Inch Lift (DEG)
284 Degree
Exhaust Valve Lift (IN)
0.704 Inch
Grind Number
304RX-8
Intake Duration At 0.050 Inch Lift (DEG)
271 Degree
Intake Valve Lift (IN)
0.698 Inch
Lobe Separation Angle (DEG)
108 Degree
Recommended Use
Serious Street Performance To All-Out Racing
RPM - High
7000
Share this page

COMP Cams Camshaft

Camshaft; Classic Series.; Dodge R5 Block; Roller; 271 Degree Intake Duration @ 0.050 Inch Lift; 284 Degree Exhaust Duration @ 0.050 Inch Lift; 0.698 Inch Intake Valve Lift; 0.704 Inch Exhaust Valve Lift; 108 Degree Lobe Separation

MPN: 5580210

Recommended Use: Serious Street Performance To All-Out Racing
Type: Roller
RPM - Low: 3800
RPM - High: 7000
Intake Duration At 0.050 Inch Lift (DEG): 271 Degree
Exhaust Duration At 0.050 Inch Lift (DEG): 284 Degree
Advertised Intake Duration (DEG): RX304 Degree
Advertised Exhaust Duration (DEG): RZ317 Degree
Intake Valve Lift (IN): 0.698 Inch
Exhaust Valve Lift (IN): 0.704 Inch
Lobe Separation Angle (DEG): 108 Degree
Grind Number: 304RX-8
Computer-Controlled Compatible: No

Features

  • Limited 1 Year Warranty
Specifications of COMP Cams Camshaft 5580210
Advertised Exhaust Duration (DEG) RZ317 Degree
Advertised Intake Duration (DEG) RX304 Degree
Computer-Controlled Compatible No
Exhaust Duration At 0.050 Inch Lift (DEG) 284 Degree
Exhaust Valve Lift (IN) 0.704 Inch
Grind Number 304RX-8
Intake Duration At 0.050 Inch Lift (DEG) 271 Degree
Intake Valve Lift (IN) 0.698 Inch
Lobe Separation Angle (DEG) 108 Degree
Recommended Use Serious Street Performance To All-Out Racing
RPM - High 7000
RPM - Low 3800
Type Roller

1900 Chrysler 273-360 LA

1900 Chrysler 361/383/400 B

1963 Dodge 330
1964 Dodge 330

1963 Dodge 440
1964 Dodge 440

1964 Dodge A100
1965 Dodge A100
1966 Dodge A100

1970 Dodge A100

1964 Dodge A100 Truck
1965 Dodge A100 Truck
1966 Dodge A100 Truck
1967 Dodge A100 Truck
1968 Dodge A100 Truck
1969 Dodge A100 Truck
1970 Dodge A100 Truck

1976 Dodge Aspen
1977 Dodge Aspen
1978 Dodge Aspen
1979 Dodge Aspen
1980 Dodge Aspen

1975 Dodge B100
1976 Dodge B100
1977 Dodge B100
1978 Dodge B100
1979 Dodge B100
1980 Dodge B100

1971 Dodge B100 Van
1972 Dodge B100 Van
1973 Dodge B100 Van
1974 Dodge B100 Van

1975 Dodge B200
1976 Dodge B200
1977 Dodge B200
1978 Dodge B200
1979 Dodge B200
1980 Dodge B200

1971 Dodge B200 Van
1972 Dodge B200 Van
1973 Dodge B200 Van
1974 Dodge B200 Van

1975 Dodge B300
1976 Dodge B300
1977 Dodge B300
1978 Dodge B300
1979 Dodge B300
1980 Dodge B300

1971 Dodge B300 Van
1972 Dodge B300 Van
1973 Dodge B300 Van
1974 Dodge B300 Van

1973 Dodge CB300
1974 Dodge CB300
1975 Dodge CB300
1976 Dodge CB300
1977 Dodge CB300
1978 Dodge CB300
1979 Dodge CB300
1980 Dodge CB300

1970 Dodge Challenger
1971 Dodge Challenger
1972 Dodge Challenger
1973 Dodge Challenger
1974 Dodge Challenger

1966 Dodge Charger
1967 Dodge Charger
1968 Dodge Charger
1969 Dodge Charger
1970 Dodge Charger
1971 Dodge Charger
1972 Dodge Charger
1973 Dodge Charger
1974 Dodge Charger
1975 Dodge Charger
1976 Dodge Charger
1977 Dodge Charger
1978 Dodge Charger

1958 Dodge Coronet

1965 Dodge Coronet
1966 Dodge Coronet
1967 Dodge Coronet
1968 Dodge Coronet
1969 Dodge Coronet
1970 Dodge Coronet
1971 Dodge Coronet
1972 Dodge Coronet
1973 Dodge Coronet
1974 Dodge Coronet
1975 Dodge Coronet
1976 Dodge Coronet

1958 Dodge Custom

1975 Dodge D100
1976 Dodge D100
1977 Dodge D100
1978 Dodge D100
1979 Dodge D100

1958 Dodge D100 Pickup
1959 Dodge D100 Pickup

1968 Dodge D100 Pickup
1969 Dodge D100 Pickup
1970 Dodge D100 Pickup
1971 Dodge D100 Pickup
1972 Dodge D100 Pickup
1973 Dodge D100 Pickup
1974 Dodge D100 Pickup

1960 Dodge D100 Series
1961 Dodge D100 Series
1962 Dodge D100 Series
1963 Dodge D100 Series
1964 Dodge D100 Series
1965 Dodge D100 Series
1966 Dodge D100 Series
1967 Dodge D100 Series

1977 Dodge D150
1978 Dodge D150
1979 Dodge D150
1980 Dodge D150

1975 Dodge D200
1976 Dodge D200
1977 Dodge D200
1978 Dodge D200
1979 Dodge D200
1980 Dodge D200

1958 Dodge D200 Pickup
1959 Dodge D200 Pickup

1968 Dodge D200 Pickup
1969 Dodge D200 Pickup
1970 Dodge D200 Pickup
1971 Dodge D200 Pickup
1972 Dodge D200 Pickup
1973 Dodge D200 Pickup
1974 Dodge D200 Pickup

1960 Dodge D200 Series
1961 Dodge D200 Series
1962 Dodge D200 Series
1963 Dodge D200 Series
1964 Dodge D200 Series
1965 Dodge D200 Series
1966 Dodge D200 Series
1967 Dodge D200 Series

1975 Dodge D300
1976 Dodge D300
1977 Dodge D300
1978 Dodge D300
1979 Dodge D300
1980 Dodge D300

1958 Dodge D300 Pickup
1959 Dodge D300 Pickup

1968 Dodge D300 Pickup
1969 Dodge D300 Pickup
1970 Dodge D300 Pickup
1971 Dodge D300 Pickup
1972 Dodge D300 Pickup
1973 Dodge D300 Pickup
1974 Dodge D300 Pickup

1960 Dodge D300 Series
1961 Dodge D300 Series
1962 Dodge D300 Series
1963 Dodge D300 Series
1964 Dodge D300 Series
1965 Dodge D300 Series
1966 Dodge D300 Series
1967 Dodge D300 Series

1978 Dodge D400
1979 Dodge D400
1980 Dodge D400

1978 Dodge D450
1979 Dodge D450
1980 Dodge D450

1960 Dodge Dart
1961 Dodge Dart
1962 Dodge Dart

1964 Dodge Dart
1965 Dodge Dart
1966 Dodge Dart
1967 Dodge Dart
1968 Dodge Dart
1969 Dodge Dart
1970 Dodge Dart
1971 Dodge Dart
1972 Dodge Dart
1973 Dodge Dart
1974 Dodge Dart
1975 Dodge Dart
1976 Dodge Dart

1977 Dodge Diplomat
1978 Dodge Diplomat
1979 Dodge Diplomat
1980 Dodge Diplomat

1958 Dodge Lancer

1978 Dodge Magnum
1979 Dodge Magnum

1960 Dodge Matador

1970 Dodge MB300
1971 Dodge MB300
1972 Dodge MB300
1973 Dodge MB300
1974 Dodge MB300

1980 Dodge Mirada

1968 Dodge Monaco
1969 Dodge Monaco
1970 Dodge Monaco
1971 Dodge Monaco
1972 Dodge Monaco
1973 Dodge Monaco
1974 Dodge Monaco
1975 Dodge Monaco
1976 Dodge Monaco
1977 Dodge Monaco
1978 Dodge Monaco

1970 Dodge P200
1971 Dodge P200
1972 Dodge P200

1971 Dodge P300
1972 Dodge P300

1959 Dodge P300 Series

1959 Dodge P310 Series

1959 Dodge P320 Series

1968 Dodge P375

1959 Dodge P410 Series

1959 Dodge P420 Series

1959 Dodge P450 Series

1960 Dodge Phoenix
1961 Dodge Phoenix

1960 Dodge Pioneer
1961 Dodge Pioneer

1960 Dodge Polara
1961 Dodge Polara

1963 Dodge Polara
1964 Dodge Polara
1965 Dodge Polara
1966 Dodge Polara
1967 Dodge Polara
1968 Dodge Polara
1969 Dodge Polara
1970 Dodge Polara
1971 Dodge Polara
1972 Dodge Polara
1973 Dodge Polara

1972 Dodge R300
1973 Dodge R300
1974 Dodge R300

1974 Dodge Ramcharger
1975 Dodge Ramcharger
1976 Dodge Ramcharger
1977 Dodge Ramcharger
1978 Dodge Ramcharger
1979 Dodge Ramcharger
1980 Dodge Ramcharger

1978 Dodge RD200
1979 Dodge RD200
1980 Dodge RD200

1971 Dodge RM300

1973 Dodge RM300
1974 Dodge RM300

1958 Dodge Royal

1975 Dodge Royal Monaco
1976 Dodge Royal Monaco
1977 Dodge Royal Monaco

1960 Dodge Seneca
1961 Dodge Seneca

1958 Dodge Sierra

1979 Dodge St. Regis
1980 Dodge St. Regis

1958 Dodge Suburban

1958 Dodge Truck
1959 Dodge Truck
1960 Dodge Truck

1975 Dodge W100
1976 Dodge W100
1977 Dodge W100

1959 Dodge W100 Pickup

1968 Dodge W100 Pickup
1969 Dodge W100 Pickup
1970 Dodge W100 Pickup
1971 Dodge W100 Pickup
1972 Dodge W100 Pickup
1973 Dodge W100 Pickup
1974 Dodge W100 Pickup

1960 Dodge W100 Series
1961 Dodge W100 Series
1962 Dodge W100 Series
1963 Dodge W100 Series
1964 Dodge W100 Series
1965 Dodge W100 Series
1966 Dodge W100 Series
1967 Dodge W100 Series

1977 Dodge W150
1978 Dodge W150
1979 Dodge W150
1980 Dodge W150

1975 Dodge W200
1976 Dodge W200
1977 Dodge W200
1978 Dodge W200
1979 Dodge W200
1980 Dodge W200

1959 Dodge W200 Pickup

1968 Dodge W200 Pickup
1969 Dodge W200 Pickup
1970 Dodge W200 Pickup
1971 Dodge W200 Pickup
1972 Dodge W200 Pickup
1973 Dodge W200 Pickup
1974 Dodge W200 Pickup

1960 Dodge W200 Series
1961 Dodge W200 Series
1962 Dodge W200 Series
1963 Dodge W200 Series
1964 Dodge W200 Series
1965 Dodge W200 Series
1966 Dodge W200 Series
1967 Dodge W200 Series

1975 Dodge W300
1976 Dodge W300
1977 Dodge W300
1978 Dodge W300
1979 Dodge W300
1980 Dodge W300

1959 Dodge W300 Pickup

1968 Dodge W300 Pickup
1969 Dodge W300 Pickup
1970 Dodge W300 Pickup
1971 Dodge W300 Pickup
1972 Dodge W300 Pickup
1973 Dodge W300 Pickup
1974 Dodge W300 Pickup

1960 Dodge W300 Series
1961 Dodge W300 Series
1962 Dodge W300 Series
1963 Dodge W300 Series
1964 Dodge W300 Series
1965 Dodge W300 Series
1966 Dodge W300 Series
1967 Dodge W300 Series

1960 Dodge Wm300 Power Wagon
1961 Dodge Wm300 Power Wagon
1962 Dodge Wm300 Power Wagon
