COMP Cams Camshaft 416017

Name: COMP Cams Camshaft 416017
Brand: COMP Cams
SKU: 41-601-7
Price: 805.99 USD
Availability: InStock

Authorized Dealer

Brand:

COMP Cams

0 reviews

Have a product question? Ask us
Part Number: 41-601-7
Part Location: U.S.
Availability: *Special Order
Delivery: Up to 2 Weeks
If purchased before 12:00 EDT - estimated delivery by July 21

Retail: $846.29

Price: $805.99

You Save: $40.30

Advertised Exhaust Duration (DEG)

307 Degree

Advertised Intake Duration (DEG)

275 Degree

Computer-Controlled Compatible

Engine Compatibility

Ford V8 239-255 Cubic Inch

Exhaust Duration At 0.050 Inch Lift (DEG)

249 Degree

Exhaust Valve Lift (IN)

0.364 Inch

Grind Number

275TS7

Intake Centerline Angle (DEG)

102 Degree

Intake Duration At 0.050 Inch Lift (DEG)

235 Degree

Intake Valve Lift (IN)

0.368 Inch

Lobe Separation Angle (DEG)

107 Degree

Share this page

COMP Cams Camshaft

Camshaft; Thumpr ™; Fort Flathead 3.9L-4.2L/239-255 Cubic Inch; Mechanical Flat Tappet; 2200-6100 RPM Range; 235 Degree Intake Duration @ 0.050 Inch Lift; 249 Degree Exhaust Duration @ 0.050 Inch Lift; 0.368 Inch Intake Valve Lift; 0.364 Inch Exhaust Valve Lift; 107 Degree Lobe Separation

MPN: 416017

The Thumpr™ Camshafts are a series of hydraulic flat tappet and hydraulic roller Camshafts that are now available for most popular applications, carb and late model EFI. The reason that the new Thumpr™ Camshafts have such an aggressive exhaust note is that the lobe profiles and grind characteristics chosen by the COMP Cams(R) engineers produce a combination of early exhaust Valve opening, long exhaust duration and a generous amount of intake and exhaust overlap to maximize the rough idling characteristics of the cams without negatively impacting the power output or streetability. Thumpr™ cams deliver incredible muscle car sound and a new level of streetable performance.

Engine Compatibility: Ford V8 239-255 Cubic Inch

Recommended Use: Moderate Street Performance To Serious Race

Type: Mechanical Flat Tappet

RPM - Low: 2200

RPM - High: 6100

Intake Duration At 0.050 Inch Lift (DEG): 235 Degree

Exhaust Duration At 0.050 Inch Lift (DEG): 249 Degree

Advertised Intake Duration (DEG): 275 Degree

Advertised Exhaust Duration (DEG): 307 Degree

Intake Valve Lift (IN): 0.368 Inch

Exhaust Valve Lift (IN): 0.364 Inch

Lobe Separation Angle (DEG): 107 Degree

Intake Centerline Angle (DEG): 102 Degree

Grind Number: 275TS7

Computer-Controlled Compatible: No

Features

Available In Both Hydraulic Flat Tappet And Hydraulic Roller Designs For Most Popular Applications, Carb And Late Model EFI
Three Unique Grinds For Each Engine To Fit All Cruising And Street Performance Needs
Long Exhaust Duration And Other Grind Characteristics Produce A Powerful, Hard Hitting Exhaust Note
Designed For Use With The Latest In Valve Train Component Advancements Such As Beehive™ Valve Springs, Pro Magnum™ Roller Rockers And Magnum Pushrods
Limited 1 Year Warranty

Specifications of COMP Cams Camshaft 416017
Advertised Exhaust Duration (DEG)	307 Degree
Advertised Intake Duration (DEG)	275 Degree
Computer-Controlled Compatible	No
Engine Compatibility	Ford V8 239-255 Cubic Inch
Exhaust Duration At 0.050 Inch Lift (DEG)	249 Degree
Exhaust Valve Lift (IN)	0.364 Inch
Grind Number	275TS7
Intake Centerline Angle (DEG)	102 Degree
Intake Duration At 0.050 Inch Lift (DEG)	235 Degree
Intake Valve Lift (IN)	0.368 Inch
Lobe Separation Angle (DEG)	107 Degree
Recommended Use	Moderate Street Performance To Serious Race
RPM - High	6100
RPM - Low	2200
Type	Mechanical Flat Tappet
