Wilwood Brakes Brake Rotor - 160-7104-BK
Design
2-Piece
Disc To Hat Bolt Circle (IN)
8 X 7 Inch
Disc To Hat Bolt Circle (MM)
8 X 175 Millimeter
Disc Type
Drilled And Slotted
Finish
Electro Coated
Material
Iron
Nominal Thickness (IN)
0.81 Inch
Nominal Thickness (MM)
20.57 Millimeter
Outer Diameter (IN)
12.19 Inch
Outer Diameter (MM)
309.62 Millimeter
Quantity
Single
Share this page
Wilwood Brakes Brake Rotor
Brake Rotor; SRP; Vented Drilled and Slotted; 2 Piece without Hat; Rotor To Hat Bolt Pattern 8 X 7.00 Inches; Left Side; 12.19 Inch Diameter x 0.81 Inch Thickness; Black Electro Coated Iron; Single
MPN: 1607104BK
SRP Drilled Performance Rotors feature a specially engineered directional cross drill and face slot pattern that improve brake response and pad performance throughout the entire range of light to heavy braking. The venting and cleaning action of the holes and slots will reduce pad glaze and disperse gasses and heat generated during the pad to rotor interface. The holes and slots also inhibit irregular pad compound build-up on the rotor faces resulting in smoother engagement and improved pedal response in all conditions. The material removed also contributes to lower rotating and unsprung suspension weight. Rotors are treated with a black electro coat to inhibit corrosion on all areas of the rotor, including the interior vanes to which other coatings like zinc, won’t adhere
Recommended Use: Racing/ Street
Design: 2-Piece
Disc Type: Drilled And Slotted
Finish: Electro Coated
Material: Iron
Outer Diameter (IN): 12.19 Inch
Outer Diameter (MM): 309.62 Millimeter
Nominal Thickness (IN): 0.81 Inch
Nominal Thickness (MM): 20.57 Millimeter
Disc To Hat Bolt Circle (IN): 8 X 7 Inch
Disc To Hat Bolt Circle (MM): 8 X 175 Millimeter
Quantity: Single
Features
- Feature A Specially Engineered Directional Cross Drill And Face Slot Pattern That Improves Brake Response And Pad Performance Throughout The Entire Range Of Light To Heavy Braking
- The Venting And Cleaning Action Of The Holes And Slots Will Reduce Pad Glaze And Disperse Gasses And Heat Generated During The Pad To Rotor Interface
- The Holes And Slots Also Inhibit Irregular Pad Compound Build-Up On The Rotor Faces Resulting In Smoother Engagement And Improved Pedal Response In All Conditions
- The Material Removed Also Contributes To Lower Rotating Mass And Unsprung Suspension Weight
- Rotors Are Treated With A Black Electro Coat To Inhibit Corrosion On All Areas Of The Rotor, Including The Interior Vanes To Which Other Coatings Like Zinc
- No Supplier Warranty
Specifications of Wilwood Brakes Brake Rotor - 160-7104-BK | |
Design | 2-Piece |
Disc To Hat Bolt Circle (IN) | 8 X 7 Inch |
Disc To Hat Bolt Circle (MM) | 8 X 175 Millimeter |
Disc Type | Drilled And Slotted |
Finish | Electro Coated |
Material | Iron |
Nominal Thickness (IN) | 0.81 Inch |
Nominal Thickness (MM) | 20.57 Millimeter |
Outer Diameter (IN) | 12.19 Inch |
Outer Diameter (MM) | 309.62 Millimeter |
Quantity | Single |
Recommended Use | Racing/ Street |
