Turbo Smart Turbocharger Wastegate - TS-0552-1101

Brand: Turbo Smart
0 reviews
  • Have a product question? Ask us
  • Part Number: TS-0552-1101
  • Part Location: U.S.
  • Availability: Out Of Stock
Retail: $460.94
Price: $438.99
You Save: $21.95
Control
Mechanical
Diameter
1-3/4 Inch
PSI Range
14 Pounds Per Square Inch
Type
External
Wastegate Base Material
Cast Stainless Steel
Share this page

Turbo Smart Turbocharger Wastegate

Turbocharger Wastegate; Gen-V Comp-Gate40; For Motorsports Applications; Blue; 40 MM; With Inlet and Outlet Flanges/ V-Band Clamps/ Valve Seat/ Vacuum Fittings/ Built In Heatsink

MPN: TS05521101

The GenV CompGate40 HP external wastegate is a Motorsport proved, cost-effective external wastegate with base spring pressure options of up to 50psi! Add to that some reference signal manipulation and you have some serious boost! The GenV provides extensive user configurability, world-leading extended thermal performance, fatigue resistance, and best-in-class flow performance for optimum control and longevity. The GenV External Wastegate from Turbosmart was a ground-up rework of a classic and the only feature that rolled over from the Gen4 range was the mounting orientation. CFD optimized and validated in-house for maximum flow and thermal management, the GenV range has more features, options, and performance than any other gate like it.
Type: External
PSI Range: 14 Pounds Per Square Inch
Control: Mechanical
Diameter: 1-3/4 Inch
Wastegate Base Material: Cast Stainless Steel

Please refer the Technical Bulletins attached to the Product Manual tab

Features

  • CFD Optimized And Validated In-House For Maximum Flow And Thermal Management
  • The GenV Range Has More Features, Options And Performance Than Any Other Gate Like It
  • Unique Collar-Locking System, Variable Actuator Cap And Base For Easy
  • 60 Degree Optional Routing Of Reference Hoses, Strap-Type V-Band Clamps
  • Nitronic 60 Valve Guide And High Temp 347 Stainless Steel Body
  • Limited 1 Year Warranty
Specifications of Turbo Smart Turbocharger Wastegate - TS-0552-1101
Control Mechanical
Diameter 1-3/4 Inch
PSI Range 14 Pounds Per Square Inch
Type External
Wastegate Base Material Cast Stainless Steel
