Turbo Smart Fuel Pressure Regulator - TS-0401-1115

Brand: Turbo Smart
0 reviews
  • Have a product question? Ask us
  • Part Number: TS-0401-1115
  • Part Location: U.S.
  • Availability: *Special Order
  • Delivery: Up to 2 Weeks
  • If purchased before 12:00 EDT - estimated delivery by July 17
Retail: $319.19
Price: $303.99
You Save: $15.20
Color
Black
Finish
Black Anodized
Fuel Type
Gasoline/ E85
Gauge Port
Yes
Includes Fittings
No
Includes Mounting Brackets
No
Inlet Attachment
Female Straight Cut O-Ring
Inlet Quantity
Two
Inlet Size
1/2 Inch (-8AN)
Material
Aluminum
Outlet Attachment
Female Straight Cut O-Ring
Share this page

Turbo Smart Fuel Pressure Regulator

Fuel Pressure Regulator; FPR2000; For Up To 2000 Horsepower; 30-90 PSI; -8AN Inlet/Outlets; Gasoline/ E85; Black; Aluminum; Limited Edition

MPN: TS04011115

Turbosmart’s newest High-performance EFI fuel pressure regulator is smaller, lighter and better. Featuring two -8AN inlet ports, one -8AN return port, and one 1/8 NPT gauge port, 30 to 90 PSI base pressure adjustment, 1:1 ratio, premium diaphragm and stainless steel valve + seat allow for ANY fuel type including E85 and is suitable for engines with up to 2000 horsepower fuel systems. FPR’s feature a non-directional bias to regulation, so no matter where the fuel comes in they will regulate the same. Factory tested.
Fuel Type: Gasoline/ E85
Pressure Range (PSI): 30 To 90 Pounds Per Square Inch
Regulator Location: Inline
Regulator Type: Return
Gauge Port: Yes
Inlet Attachment: Female Straight Cut O-Ring
Inlet Quantity: Two
Inlet Size: 1/2 Inch (-8AN)
Outlet Attachment: Female Straight Cut O-Ring
Outlet Quantity: Single
Outlet Size: 1/2 Inch (-8AN)
Includes Fittings: No
Includes Mounting Brackets: No
Return Port Size: 1/2 Inch (-8AN)
Finish: Black Anodized
Color: Black
Material: Aluminum

Features

  • Stainless Steel Internals Providing Maximum Integrity And Reliability
  • Capable Of Regulating Up To 2000 Horsepower Of Fuel Flow
  • 1:1 Manifold Pressure Ratio With No Load Losses
  • MILSPEC Diaphragm
  • Limited 1 Year Warranty
Specifications of Turbo Smart Fuel Pressure Regulator - TS-0401-1115
Color Black
Finish Black Anodized
Fuel Type Gasoline/ E85
Gauge Port Yes
Includes Fittings No
Includes Mounting Brackets No
Inlet Attachment Female Straight Cut O-Ring
Inlet Quantity Two
Inlet Size 1/2 Inch (-8AN)
Material Aluminum
Outlet Attachment Female Straight Cut O-Ring
Outlet Quantity Single
Outlet Size 1/2 Inch (-8AN)
Pressure Range (PSI) 30 To 90 Pounds Per Square Inch
Regulator Location Inline
Regulator Type Return
Return Port Size 1/2 Inch (-8AN)
