Sniper Motorsports Fuel Injection System - 0550868
Air Flow Rate
715 Cubic Feet Per Meter
Aspiration
Naturally Aspirated
Fuel Injection Type
Throttle Body
Includes Calibration Module
Yes
Includes Distributor
No
Includes ECM
Yes
Includes Fuel Pressure Regulator
No
Includes Fuel Pump
No
Includes Fuel Rails
No
Includes Gaskets
Yes
Includes IAC Motor
Yes
Share this page
Sniper Motorsports Fuel Injection System
Fuel Injection System; Quadrajet ™; Transmission Control For 700R4/ 200R4 Transmissions; Use With Naturally Aspirated Engines; Black Ceramic Finish; With Throttle Body Mounted ECU/ Wideband Oxygen Sensor/ Handheld EFI Controller/ Transmission Kickdown Bracket
MPN: 0550868
Are you tired of rebuilding the 50+ year old Rochester Quadrajet (Q-Jet) on your classic Chevrolet, GMC, Buick, Oldsmobile, or Pontiac. Introducing Sniper EFI Quadrajet. The first bolt on spread bore electronic fuel injected throttle body system that does not require any additional adapters, sealing plates, or intake manifold swaps! The Sniper EFI Rochester Quadrajet (Q-Jet) system retains the same great features as the 4150 Sniper EFI version such as; four 100 Pounds per Hour Injectors, built in timing control, a 3.5 Inch full color touchscreen and much more. The throttle body will support up to 500 Horsepower naturally aspirated. In addition to all of these great tried and true features, the Sniper EFI Rochester Quadrajet (Q-Jet) system will fit most stock air cleaners and offers multiple fuel inlet configurations that allow for a stock appearing installation.
Aspiration: Naturally Aspirated
Fuel Injection Type: Throttle Body
Metering Type: Speed Density
Includes Intake Manifold: No
Intake Manifold Finish: No Intake Manifold
Intake Manifold Material: No Intake Manifold
Includes Fuel Rails: No
Throttle Body Material: Aluminum
Throttle Body Mounting Flange: 4-Barrel Spread Bore
Venturi Quantity: 4
Venturi Diameter (MM): 34.93/51.00 Millimeter
Air Flow Rate: 715 Cubic Feet Per Meter
Injector Size (LB/HR): 100 Pounds Per Hour
Includes Calibration Module: Yes
Includes ECM: Yes
Includes Wiring Harness: Yes
Includes Fuel Pump: No
Includes Fuel Pressure Regulator: No
Includes Distributor: No
Includes Oxygen Sensor: Yes
Includes TPS Sensor: Yes
Includes IAT Sensor: Yes
Includes MAP Sensor: Yes
Includes IAC Motor: Yes
Includes Gaskets: Yes
Features
- Designed To Deliver The Signature Rochester Roar At Wide Open Throttle
- Supports Up To 500 Horsepower With Four 100 Pounds Per Hour Injectors
- Only 4 Wiring Connections Required! (Battery +, Battery - , Switched Ignition And RPM); Integrated Ignition Timing Control
- High Resolution Full Color Touchscreen For Initial Setup, Tuning, And Gauge Displays
- Simple Calibration Wizard - NO Laptop Required
- Self-Tuning ECU Means You Don't Have To Be A Computer Or Tuning Wiz To Have EFI; OEM Style Throttle Position Sensor (TPS) Or Idle Air Control (IAC) For Years Of Dependable Service
- Certified To ISO 8846, SAE J1171 And United States Coast Guard Requirements For Ignition Protection And Fire Resistance
- Fits Most Stock Rochester Quadrajet (Q-Jet) Air Cleaners
- Throttle Body Mounted ECU No Extra Boxes To Mount
- Limited 90 Day Supplier Warranty
| Specifications of Sniper Motorsports Fuel Injection System - 0550868 | |
| Air Flow Rate | 715 Cubic Feet Per Meter |
| Aspiration | Naturally Aspirated |
| Fuel Injection Type | Throttle Body |
| Includes Calibration Module | Yes |
| Includes Distributor | No |
| Includes ECM | Yes |
| Includes Fuel Pressure Regulator | No |
| Includes Fuel Pump | No |
| Includes Fuel Rails | No |
| Includes Gaskets | Yes |
| Includes IAC Motor | Yes |
| Includes IAT Sensor | Yes |
| Includes Intake Manifold | No |
| Includes MAP Sensor | Yes |
| Includes Oxygen Sensor | Yes |
| Includes TPS Sensor | Yes |
| Includes Wiring Harness | Yes |
| Injector Size (LB/HR) | 100 Pounds Per Hour |
| Intake Manifold Finish | No Intake Manifold |
| Intake Manifold Material | No Intake Manifold |
| Metering Type | Speed Density |
| Throttle Body Material | Aluminum |
| Throttle Body Mounting Flange | 4-Barrel Spread Bore |
| Venturi Diameter (MM) | 34.93/51.00 Millimeter |
| Venturi Quantity | 4 |
