Sniper Motorsports Fuel Injection System - 0550868

Authorized Dealer
Brand: Sniper Motorsports Sniper Motorsports
0 reviews
  • Have a product question? Ask us
  • Part Number: 0550868
  • Part Location: U.S.
  • Availability: *Special Order
  • Delivery: Up to 2 Weeks
  • If purchased before 12:00 EDT - estimated delivery by July 06
Retail: $2,254.34
Price: $2,146.99
You Save: $107.35
Air Flow Rate
715 Cubic Feet Per Meter
Aspiration
Naturally Aspirated
Fuel Injection Type
Throttle Body
Includes Calibration Module
Yes
Includes Distributor
No
Includes ECM
Yes
Includes Fuel Pressure Regulator
No
Includes Fuel Pump
No
Includes Fuel Rails
No
Includes Gaskets
Yes
Includes IAC Motor
Yes
Share this page

Sniper Motorsports Fuel Injection System

Fuel Injection System; Quadrajet ™; Transmission Control For 700R4/ 200R4 Transmissions; Use With Naturally Aspirated Engines; Black Ceramic Finish; With Throttle Body Mounted ECU/ Wideband Oxygen Sensor/ Handheld EFI Controller/ Transmission Kickdown Bracket

MPN: 0550868

Are you tired of rebuilding the 50+ year old Rochester Quadrajet (Q-Jet) on your classic Chevrolet, GMC, Buick, Oldsmobile, or Pontiac. Introducing Sniper EFI Quadrajet. The first bolt on spread bore electronic fuel injected throttle body system that does not require any additional adapters, sealing plates, or intake manifold swaps! The Sniper EFI Rochester Quadrajet (Q-Jet) system retains the same great features as the 4150 Sniper EFI version such as; four 100 Pounds per Hour Injectors, built in timing control, a 3.5 Inch full color touchscreen and much more. The throttle body will support up to 500 Horsepower naturally aspirated. In addition to all of these great tried and true features, the Sniper EFI Rochester Quadrajet (Q-Jet) system will fit most stock air cleaners and offers multiple fuel inlet configurations that allow for a stock appearing installation.
Aspiration: Naturally Aspirated
Fuel Injection Type: Throttle Body
Metering Type: Speed Density
Includes Intake Manifold: No
Intake Manifold Finish: No Intake Manifold
Intake Manifold Material: No Intake Manifold
Includes Fuel Rails: No
Throttle Body Material: Aluminum
Throttle Body Mounting Flange: 4-Barrel Spread Bore
Venturi Quantity: 4
Venturi Diameter (MM): 34.93/51.00 Millimeter
Air Flow Rate: 715 Cubic Feet Per Meter
Injector Size (LB/HR): 100 Pounds Per Hour
Includes Calibration Module: Yes
Includes ECM: Yes
Includes Wiring Harness: Yes
Includes Fuel Pump: No
Includes Fuel Pressure Regulator: No
Includes Distributor: No
Includes Oxygen Sensor: Yes
Includes TPS Sensor: Yes
Includes IAT Sensor: Yes
Includes MAP Sensor: Yes
Includes IAC Motor: Yes
Includes Gaskets: Yes

Features

  • Designed To Deliver The Signature Rochester Roar At Wide Open Throttle
  • Supports Up To 500 Horsepower With Four 100 Pounds Per Hour Injectors
  • Only 4 Wiring Connections Required! (Battery +, Battery - , Switched Ignition And RPM); Integrated Ignition Timing Control
  • High Resolution Full Color Touchscreen For Initial Setup, Tuning, And Gauge Displays
  • Simple Calibration Wizard - NO Laptop Required
  • Self-Tuning ECU Means You Don't Have To Be A Computer Or Tuning Wiz To Have EFI; OEM Style Throttle Position Sensor (TPS) Or Idle Air Control (IAC) For Years Of Dependable Service
  • Certified To ISO 8846, SAE J1171 And United States Coast Guard Requirements For Ignition Protection And Fire Resistance
  • Fits Most Stock Rochester Quadrajet (Q-Jet) Air Cleaners
  • Throttle Body Mounted ECU No Extra Boxes To Mount
  • Limited 90 Day Supplier Warranty
Specifications of Sniper Motorsports Fuel Injection System - 0550868
Air Flow Rate 715 Cubic Feet Per Meter
Aspiration Naturally Aspirated
Fuel Injection Type Throttle Body
Includes Calibration Module Yes
Includes Distributor No
Includes ECM Yes
Includes Fuel Pressure Regulator No
Includes Fuel Pump No
Includes Fuel Rails No
Includes Gaskets Yes
Includes IAC Motor Yes
Includes IAT Sensor Yes
Includes Intake Manifold No
Includes MAP Sensor Yes
Includes Oxygen Sensor Yes
Includes TPS Sensor Yes
Includes Wiring Harness Yes
Injector Size (LB/HR) 100 Pounds Per Hour
Intake Manifold Finish No Intake Manifold
Intake Manifold Material No Intake Manifold
Metering Type Speed Density
Throttle Body Material Aluminum
Throttle Body Mounting Flange 4-Barrel Spread Bore
Venturi Diameter (MM) 34.93/51.00 Millimeter
Venturi Quantity 4
