Smittybilt Winch - 17500 Pound Electric - 97417
Brake Type
Dynamic
Color
Black
Drive Gear Type
Planetary
Drum Material
Steel
Electrical Control Type
Integrated Solenoid
Estimated Install Time (Hours)
2
Fairlead Type
Roller
Free Spooling
Yes
Gear Reduction Ratio
13.750694444
Includes Mounting Hardware
Yes
Line Diameter (IN)
7/16 Inch
Share this page
Smittybilt Winch
Winch; XRC Series; Vehicle Mounted; Vehicle Recovery Winch; 12 Volt Electric; 17500 Pound Rated Pull; 93-1/2 Foot Steel Cable; 4-Way Roller Fairlead; Wired Remote; Integrated Solenoid Housing; Planetary Gear Drive
MPN: 97417
Winch Rating: 17500 Pound
Recommended Use: Vehicle Recovery
Type: Electric
Mount Type: Fixed Mount
Voltage: 12 Volt
Motor Horsepower: 6.6 Horsepower
Thermal Shutoff: No
Gear Reduction Ratio: 13.750694444
Free Spooling: Yes
Operation Type: Power
Line Length (FT): 93.5 Feet
Line Material: Steel
Fairlead Type: Roller
Remote Type: Wired
Brake Type: Dynamic
Includes Mounting Hardware: Yes
Color: Black
Mounting Pattern Size: 10 Inch Length X 4-1/2 Inch Width
Max Amp Draw: 435 Amp Draw At 17500 Pound
Line Speed At Max Pull: 3.24 Feet Per Minute At 17500 Pound
Electrical Control Type: Integrated Solenoid
Motor Type: Series Wound
Drive Gear Type: Planetary
Line Diameter (IN): 7/16 Inch
Mounting Hole Quantity: 4
Drum Material: Steel
Estimated Install Time (Hours): 2
Features
- Every Winch Is Finished In A High-Gloss Black Powder Coat With Stainless Steel Hardware
- Aluminum Cross Bars To Provide You With A Great Looking System That Will Last You A Lifetime
- Every System Includes An Illuminated Remote Control, Solenoid Box With The Versatility To Be Mounted Over The Winch Motor Or Winch Cable, A Four Way Roller Fairlead And Hook
- A Smittybilt XRC Winch Is A Complete Recovery System With The Muscle And Reliability To Bail You Out Of Any Situation
- Meets SAE J706 Standard
- Limited 2 Year Warranty
| Specifications of Smittybilt Winch - 17500 Pound Electric - 97417 | |
| Brake Type | Dynamic |
| Color | Black |
| Drive Gear Type | Planetary |
| Drum Material | Steel |
| Electrical Control Type | Integrated Solenoid |
| Estimated Install Time (Hours) | 2 |
| Fairlead Type | Roller |
| Free Spooling | Yes |
| Gear Reduction Ratio | 13.750694444 |
| Includes Mounting Hardware | Yes |
| Line Diameter (IN) | 7/16 Inch |
| Line Length (FT) | 93.5 Feet |
| Line Material | Steel |
| Line Speed At Max Pull | 3.24 Feet Per Minute At 17500 Pound |
| Max Amp Draw | 435 Amp Draw At 17500 Pound |
| Motor Horsepower | 6.6 Horsepower |
| Motor Type | Series Wound |
| Mount Type | Fixed Mount |
| Mounting Hole Quantity | 4 |
| Mounting Pattern Size | 10 Inch Length X 4-1/2 Inch Width |
| Operation Type | Power |
| Recommended Use | Vehicle Recovery |
| Remote Type | Wired |
| Thermal Shutoff | No |
| Type | Electric |
| Voltage | 12 Volt |
| Winch Rating | 17500 Pound |
