Smittybilt Winch - 3000 Pound Electric - 97203
Brake Type
Self-Locking
Color
Black
Drive Gear Type
Planetary
Drum Material
Steel
Electrical Control Type
Integrated Solenoid
Estimated Install Time (Hours)
2
Fairlead Type
Roller
Free Spooling
Yes
Gear Reduction Ratio
5.6673611111
Includes Mounting Hardware
Yes
Line Diameter (IN)
1/4 Inch
Share this page
Smittybilt Winch
Winch; XRC Series; Vehicle Mounted; ATV/ UTV Recovery Winch; 12 Volt Electric; 3000 Pound Rated Pull; 33 Foot Wire Rope; With Roller Fairlead; Wired Remote And Handle-Bar Rocker Switch; Integrated Solenoid Housing; Planetary Gear Drive
MPN: 97203
The new Smittybilt XRC 3 Winch encompasses all the best features you would want in a winch. Every XRC 3 (3000 Pounds) winch features a 3.9 Horsepower permanent magnet motor and a planetary gear system with 136:1 gear ratio that will deliver power and reliability at a premium price. This is a perfect recovery system for ATV and UTV applications, with the muscle and dependability to bail you out of any situation. The XRC 3 has all the heavy duty toughness you're looking for.
Winch Rating: 3000 Pound
Recommended Use: ATV/ UTV
Type: Electric
Mount Type: Fixed Mount
Voltage: 12 Volt
Motor Horsepower: 3.9 Horsepower
Thermal Shutoff: No
Gear Reduction Ratio: 5.6673611111
Free Spooling: Yes
Operation Type: Power
Line Length (FT): 38 Feet
Line Material: Steel
Fairlead Type: Roller
Remote Type: Wired
Brake Type: Self-Locking
Includes Mounting Hardware: Yes
Color: Black
Mounting Pattern Size: 4.9 Inch Length X 3 Inch Width
Max Amp Draw: 205 Amp Draw At 3000 Pound
Line Speed At Max Pull: 4.9 Feet Per Minute At 3000 Pound
Electrical Control Type: Integrated Solenoid
Motor Type: Permanent Magnet
Drive Gear Type: Planetary
Line Diameter (IN): 1/4 Inch
Mounting Hole Quantity: 4
Drum Material: Steel
Estimated Install Time (Hours): 2
Features
- Revolutionary Planetary Gear System Boasts An 3000 Pounds Line Rating And 136:1 Gear Ratio
- A Heavy-Duty Winching System With Great Features At An Incredible Overall Value
- Intuitive Design Ensures A Simple, Hassle Free Installation
- Meets SAE J706 Standard
- Limited 2 Year Warranty
| Specifications of Smittybilt Winch - 3000 Pound Electric - 97203 | |
| Brake Type | Self-Locking |
| Color | Black |
| Drive Gear Type | Planetary |
| Drum Material | Steel |
| Electrical Control Type | Integrated Solenoid |
| Estimated Install Time (Hours) | 2 |
| Fairlead Type | Roller |
| Free Spooling | Yes |
| Gear Reduction Ratio | 5.6673611111 |
| Includes Mounting Hardware | Yes |
| Line Diameter (IN) | 1/4 Inch |
| Line Length (FT) | 38 Feet |
| Line Material | Steel |
| Line Speed At Max Pull | 4.9 Feet Per Minute At 3000 Pound |
| Max Amp Draw | 205 Amp Draw At 3000 Pound |
| Motor Horsepower | 3.9 Horsepower |
| Motor Type | Permanent Magnet |
| Mount Type | Fixed Mount |
| Mounting Hole Quantity | 4 |
| Mounting Pattern Size | 4.9 Inch Length X 3 Inch Width |
| Operation Type | Power |
| Recommended Use | ATV/ UTV |
| Remote Type | Wired |
| Thermal Shutoff | No |
| Type | Electric |
| Voltage | 12 Volt |
| Winch Rating | 3000 Pound |
