Raybestos Brakes Brake Rotor - 680686R

Brand: Raybestos Brakes

0 reviews

Have a product question? Ask us
Part Number: 680686R
Part Location: U.S.
Availability: 11 In Stock
Delivery: Ships Out in 1 - 2 Business Days
If purchased before 12:00 EDT - estimated delivery by July 07

Retail: $72.44

Price: $68.99

You Save: $3.45

Design

1-Piece

Disc To Hat Bolt Circle (IN)

Not Applicable

Disc To Hat Bolt Circle (MM)

Not Applicable

Disc Type

Solid

Finish

Natural

Height (IN)

1.52 Inch

Height (MM)

Hub Bore Size

No Hub

Material

Nominal Thickness (IN)

0.43 Inch

Nominal Thickness (MM)

10.92 Millimeter

Share this page

Raybestos Brakes Brake Rotor

Brake Rotor; R-Line; OE Replacement; Single

MPN: 680686R

Raybestos Professional Grade rotors offer full coverage with exclusive access to the Aftermarket’s latest products.

Recommended Use: Import And Domestic Cars, Light Trucks And SUVs

Design: 1-Piece

Disc Type: Solid

Finish: Natural

Material: Iron

Outer Diameter (IN): 12.99 Inch

Outer Diameter (MM): 329.94 Millimeter

Height (IN): 1.52 Inch

Height (MM): OEM

Nominal Thickness (IN): 0.43 Inch

Nominal Thickness (MM): 10.92 Millimeter

Hub Bore Size: No Hub

Wheel Bolt Circle (IN): 5 X 4.5 Inch

Wheel Bolt Circle (MM): OEM

Disc To Hat Bolt Circle (IN): Not Applicable

Disc To Hat Bolt Circle (MM): Not Applicable

Quantity: Single

Features

Developed From Oe Samples, Validated To Meet Ts16949 Quality System Standards
Meet Sae Standard For Tensile Strength - Oe-Matched, G3000 Qualified Material For Structural Integrity And Maximum Service Life
Industry Leading Coverage - 99.8 Percent Coverage For Import And Domestic Cars, Light Trucks And Suvs
Tight Lateral Run Out - 0.004 Inch Or Less For Less Pedal Pulsation And Brake Noise, Extended Pad Life
Minimal Thickness Variation - Thickness Variation Less Than 0.0005 Inch, Less Pedal Pulsation And Brake Noise
Mill Balanced Edges - 100 Percent Validation Ensures Proper Balance, Minimizes Vibration
Non-Directional Ground Finish - Ready To Install Right Out Of The Box
Limited Supplier Warranty

Specifications of Raybestos Brakes Brake Rotor - 680686R
Design	1-Piece
Disc To Hat Bolt Circle (IN)	Not Applicable
Disc To Hat Bolt Circle (MM)	Not Applicable
Disc Type	Solid
Finish	Natural
Height (IN)	1.52 Inch
Height (MM)	OEM
Hub Bore Size	No Hub
Material	Iron
Nominal Thickness (IN)	0.43 Inch
Nominal Thickness (MM)	10.92 Millimeter
Outer Diameter (IN)	12.99 Inch
Outer Diameter (MM)	329.94 Millimeter
Quantity	Single
Recommended Use	Import And Domestic Cars, Light Trucks And SUVs
Wheel Bolt Circle (IN)	5 X 4.5 Inch
Wheel Bolt Circle (MM)	OEM

2011-2014 Ford Edge

2011 Ford Edge
2012 Ford Edge
2013 Ford Edge
2014 Ford Edge

2011-2019 Ford Explorer

2011 Ford Explorer
2012 Ford Explorer
2013 Ford Explorer
2014 Ford Explorer
2015 Ford Explorer
2016 Ford Explorer
2017 Ford Explorer
2018 Ford Explorer
2019 Ford Explorer

2009-2019 Ford Flex

2009 Ford Flex
2010 Ford Flex
2011 Ford Flex
2012 Ford Flex
2013 Ford Flex
2014 Ford Flex
2015 Ford Flex
2016 Ford Flex
2017 Ford Flex
2018 Ford Flex
2019 Ford Flex

2009-2019 Ford Taurus

2009 Ford Taurus
2010 Ford Taurus
2011 Ford Taurus
2012 Ford Taurus
2013 Ford Taurus
2014 Ford Taurus
2015 Ford Taurus
2016 Ford Taurus
2017 Ford Taurus
2018 Ford Taurus
2019 Ford Taurus

2009-2009 Ford Taurus X

2009 Ford Taurus X

2009-2012 Lincoln MKS

2009 Lincoln MKS
2010 Lincoln MKS
2011 Lincoln MKS
2012 Lincoln MKS

2010-2019 Lincoln MKT

2010 Lincoln MKT
2011 Lincoln MKT
2012 Lincoln MKT
2013 Lincoln MKT
2014 Lincoln MKT
2015 Lincoln MKT
2016 Lincoln MKT
2017 Lincoln MKT
2018 Lincoln MKT
2019 Lincoln MKT

2011-2015 Lincoln MKX

2011 Lincoln MKX
2012 Lincoln MKX
2013 Lincoln MKX
2014 Lincoln MKX
2015 Lincoln MKX

2009-2009 Mercury Sable

2009 Mercury Sable
