Rancho Shock Absorber - RS55214

Brand: Rancho
  • Have a product question? Ask us
  • Part Number: RS55214
  • Part Location: U.S.
  • Availability: *Special Order
  • Delivery: 2 - 3 Weeks
Retail: $73.49
Price: $69.99
You Save: $3.50
Adjustable
No
Body Color
White
Body Material
Steel
Compressed Length (IN)
9.688 Inch
Estimated Install Time (Hours)
0.5
Extended Length (IN)
14.313 Inch
Includes Boot
Yes
Includes Dust Shield
No
Includes Hardware
Yes
Internal Design
Twin Tube
Lower Mounting Style
Eyelet
Share this page

Rancho Shock Absorber

Shock Absorber; RS5000X; Nitrogen Gas Charged; Limited Lifetime Warranty; Non Adjustable Valving; With Shock Boots; White Shock Body With Red Shock Boots; Single; Also Use RS5214

MPN: RS55214

The core of this new and innovative shock from Rancho® is the unique and patented rebound valving system and an advanced compression phase of the shock absorber. This proprietary process developed by the ride engineers at Rancho will elevate the overall handling and performance of your vehicle on and off-road.
Type: Nitrogen Gas Charged
With Coil Spring: No
Internal Design: Twin Tube
Adjustable: No
Extended Length (IN): 14.313 Inch
Compressed Length (IN): 9.688 Inch
Upper Mounting Style: Stud
Lower Mounting Style: Eyelet
Body Color: White
Quantity: Single
Rod Diameter (IN): 5/8 Inch
Valving Type: Application Specific Valving
Rod Finish: Nitrocarburized
Rod Material: Steel
Body Material: Steel
With Reservoir: No
Includes Dust Shield: No
Includes Hardware: Yes
Includes Boot: Yes
Estimated Install Time (Hours): 0.5

Features

  • Progressive Engagement Valving Will Further Engage To Maintain Control And Stability
  • Tuned Compression Control Valve: The Precision-Tuned Shim Stacked Valving Allows The Motion Of The Shock To Work In Harmony With The Vehicle During On- And Off-road Driving
  • Enlarged 2-1/4 Inch Twin Tube Body: A Larger Shock Body Allows For Increased Fluid Capacity To Operate Cooler And To Increase Vehicle Control And Performance At Varying Speeds And Terrains
  • Gas Pressurization Of Shock: Has A Variety Of Advantages Including Minimizing Air-To-Oil Mixture That Can Cause Foaming And Shock Fade; Gas Pressurization Also Provides A Mild Boost Of Spring Rate To
  • 16 Millimeter Nitro-Carburized Rod: From Increased Scuffing Resistance To Additional Protection Against Corrosion, The Process Enhances The Shock’s Overall Durability
  • Full-Displaced 35 Millimeter Bore: Helps To Provide Heightened Control Of Shock Motion Due Largely To The Expanded Piston Area
  • 1-3/8 Inch Diameter Sintered Iron Piston: Brings Increased Structural Conformity To Each Piston
  • Rebound Bumper: Greatly Reduces Wear And Tear During On And Off Road Driving
  • Glass-Filled, Fluon Banded Piston: Provides Smoother Piston Travel And Greater Responsiveness To Changing Road Conditions
  • Limited Lifetime Warranty
Specifications of Rancho Shock Absorber - RS55214
Adjustable No
Body Color White
Body Material Steel
Compressed Length (IN) 9.688 Inch
Estimated Install Time (Hours) 0.5
Extended Length (IN) 14.313 Inch
Includes Boot Yes
Includes Dust Shield No
Includes Hardware Yes
Internal Design Twin Tube
Lower Mounting Style Eyelet
Quantity Single
Rod Diameter (IN) 5/8 Inch
Rod Finish Nitrocarburized
Rod Material Steel
Type Nitrogen Gas Charged
Upper Mounting Style Stud
Valving Type Application Specific Valving
With Coil Spring No
With Reservoir No

1996 Acura SLX
1997 Acura SLX
1998 Acura SLX
1999 Acura SLX

1994 Honda Passport
1995 Honda Passport

1990 Isuzu Amigo
1991 Isuzu Amigo
1992 Isuzu Amigo
1993 Isuzu Amigo
1994 Isuzu Amigo

1989 Isuzu Pickup
1990 Isuzu Pickup
1991 Isuzu Pickup
1992 Isuzu Pickup
1993 Isuzu Pickup
1994 Isuzu Pickup
1995 Isuzu Pickup

1991 Isuzu Rodeo
1992 Isuzu Rodeo
1993 Isuzu Rodeo
1994 Isuzu Rodeo
1995 Isuzu Rodeo

1989 Isuzu Trooper
1990 Isuzu Trooper
1991 Isuzu Trooper
1992 Isuzu Trooper
1993 Isuzu Trooper
1994 Isuzu Trooper
1995 Isuzu Trooper
1996 Isuzu Trooper
1997 Isuzu Trooper
1998 Isuzu Trooper
1999 Isuzu Trooper
2000 Isuzu Trooper
2001 Isuzu Trooper
2002 Isuzu Trooper

1999 Isuzu VehiCROSS
2000 Isuzu VehiCROSS
2001 Isuzu VehiCROSS

1987 Nissan Pathfinder
1988 Nissan Pathfinder
1989 Nissan Pathfinder
1990 Nissan Pathfinder
1991 Nissan Pathfinder
1992 Nissan Pathfinder
1993 Nissan Pathfinder
1994 Nissan Pathfinder
1995 Nissan Pathfinder
