Northern Radiator Radiator 205214

Name: Northern Radiator Radiator 205214
Brand: Northern Radiator
SKU: 205214
Price: 443.99 USD
Availability: InStock

Authorized Dealer

Brand:

Northern Radiator

0 reviews

Have a product question? Ask us
Part Number: 205214
Part Location: U.S.
Availability: *Special Order
Delivery: Up to 2 Weeks
If purchased before 12:00 EDT - estimated delivery by July 07

Retail: $466.19

Price: $443.99

You Save: $22.20

Color

Silver

Core Depth (IN)

2-1/8 Inch

Core Height (IN)

15-5/8 Inch

Core Length (IN)

19-1/4 Inch

Core Material

Aluminum

Core Rows

2 Rows Of 1 Inch Tubes

Flow Direction

Downflow

Includes Fittings

Yes

Includes Mounting Hardware

Inlet Hose Location

OEM

Inlet Size (IN)

1-1/2 Inch

Share this page

Northern Radiator Radiator

Radiator; Muscle Car; Overall Dimensions 21-7/8 Inch Width x 19-3/4 Inch Height x 2-1/2 Inch Depth; Core Dimensions 19-1/4 Inch Width x 15-5/8 Inch Height x 2-1/8 Inch Depth; 2 Rows Of 1 Inch Tubes; Downflow; Aluminum; 1-1/2 Inch Upper Right Inlet x 1-3/4 Inch Lower Right Outlet; With 7 Plate Aluminum Transmission Cooler With 1/8-27 Inch NPT Fittings

MPN: 205214

When you want quality and dependability, you want Northern Radiator! From hobby and restoration to high performance racing, Northern Radiator has you covered. The most complete all makes/all models program in the industry.

Flow Direction: Downflow

Overall Length (IN): 21-7/8 Inch

Overall Height (IN): 19-3/4 Inch

Overall Depth (IN): 2-1/2 Inch

Core Rows: 2 Rows Of 1 Inch Tubes

Core Length (IN): 19-1/4 Inch

Core Height (IN): 15-5/8 Inch

Core Depth (IN): 2-1/8 Inch

Core Material: Aluminum

Inlet Hose Location: OEM

Inlet Size (IN): 1-1/2 Inch

Outlet Hose Location: OEM

Outlet Size (IN): 1-3/4 Inch

Color: Silver

Tank Material: Aluminum

With Radiator Cap: No

With Transmission Cooler: Yes

With Engine Oil Cooler: No

Includes Fittings: Yes

Includes Mounting Hardware: No

Please refer the Technical Bulletins attached to the Product Manual tab

Features

Core Has 2 Rows Of 1 Inch Tubes
Features 7 Plate Aluminum High Performance Transmission Cooler
Machined Billet Aluminum SAE Compliant Filler Neck
Features Northern Radiator Cooling Technology
Lighter Than Copper Or Brass, But Provides Up To 75 Percent More Cooling Capacity
Thick Hose Connection For Durable, No Leak Plumbing
Application(Vehicle) Specific Design For Maximum Cooling
All Welded Construction
75+ Models Cover Hundreds Of Truck And Passenger Application
Limited 1 Year Warranty

Specifications of Northern Radiator Radiator 205214
Color	Silver
Core Depth (IN)	2-1/8 Inch
Core Height (IN)	15-5/8 Inch
Core Length (IN)	19-1/4 Inch
Core Material	Aluminum
Core Rows	2 Rows Of 1 Inch Tubes
Flow Direction	Downflow
Includes Fittings	Yes
Includes Mounting Hardware	No
Inlet Hose Location	OEM
Inlet Size (IN)	1-1/2 Inch
Outlet Hose Location	OEM
Outlet Size (IN)	1-3/4 Inch
Overall Depth (IN)	2-1/2 Inch
Overall Height (IN)	19-3/4 Inch
Overall Length (IN)	21-7/8 Inch
Tank Material	Aluminum
With Engine Oil Cooler	No
With Radiator Cap	No
With Transmission Cooler	Yes
