MSD Ignition Ignition System Kit 6214
Compatibility
Midget Sprint Race Vehicles
Includes Distributor
No
Includes Ignition Coil
No
Includes Spark Plug Wire Separators
Yes
Includes Spark Plug Wires
Yes
Includes Wiring Harness
Yes
Spark Plug Wire Color
Red
Spark Plug Wire Diameter (MM)
8.5 Millimeter
Share this page
MSD Ignition Ignition System Kit
Ignition System Kit; For Use With Midget Sprint Race Vehicles; Includes Ignition Control/2 Non-Magnetic Pickups/Trigger Magnet/On-Off Switch/Software
MPN: 6214
The programmable midget ignition is a complete electronic distributor less system consisting of a powerful capacitive discharge ignition control, a four tower high output coil pack and uses two non magnetic pickups with a trigger wheel as a crank trigger source. This takes all of the mechanical variables out of the picture to produce exact ignition timing! Adding to the accuracy and high output of this ignition system, is the advantage of being able to precisely program the timing throughout the engine’s entire RPM range. By using the optional hand held programmer, MSD’s Pro-Data and software package on a windows based PC, racers can program two different timing curves down to 0.1 Inch per 100 RPM increments! Other features of the programmable midget ignition include a rev limiter to protect the engine from over-rev damage, a start retard and a circuit that monitors the battery supply voltage. The midget ignition produces full power capacitive discharge sparks at any RPM so you can be assured of complete combustion. To control this power and the programs, a 15 Megahertz microcontroller analyzes the various inputs and is capable of extremely quick compensations to maintain exact timing and RPM. The midget ignition is supplied with the ignition control, two non magnetic pickups, trigger magnet, on/off switch and software
Compatibility: Midget Sprint Race Vehicles
Includes Distributor: No
Includes Ignition Coil: No
Includes Spark Plug Wires: Yes
Spark Plug Wire Diameter (MM): 8.5 Millimeter
Spark Plug Wire Color: Red
Includes Spark Plug Wire Separators: Yes
Includes Wiring Harness: Yes
Features
- Plot Two Timing Curves Ranging From 800 To 15000 RPM In 0.1 Degree Increments
- Program A Start Retard To Ease Cranking
- Select A Rev Limit From 2000 To 15000 RPM In 100 RPM Increments
- A Battery Monitor Circuit Shows Real Time Battery Voltage And A Low Voltage Time Percentage
- Switch Between Two Timing Curves As Track Conditions Change During A Race
- Limited 1 Year Warranty
| Specifications of MSD Ignition Ignition System Kit 6214 | |
| Compatibility | Midget Sprint Race Vehicles |
| Includes Distributor | No |
| Includes Ignition Coil | No |
| Includes Spark Plug Wire Separators | Yes |
| Includes Spark Plug Wires | Yes |
| Includes Wiring Harness | Yes |
| Spark Plug Wire Color | Red |
| Spark Plug Wire Diameter (MM) | 8.5 Millimeter |
