JE Pistons Piston - 212157
Bore Size (IN)
4-1/4 Inch
Connecting Rod Material
No Connecting Rod
Dome Volume
18 Cubic Centimeter
Engine Compatibility
Chevy Big Block V8 7.4L 454 Cubic Inch
Includes Piston Rings
No
Material
Aluminum Alloy
Oversized
0.060 Inch
Piston Type
Dome Top
Quantity
Set Of 8
Wrist Pin Style
Floating
Share this page
JE Pistons Piston
Piston; SRP; For Use With Big Block Chevy 496 Engines; Forged; 4.250 Inch Bore; 0.060 Inch Oversized; 4.250 Inch Stroke/ 6.385 Inch Rod Length; 1.270 Inch Compression Distance; Dome Top/ 18 CC Volume; 10.7:1 Compression Ratio With 112 CC Heads/ 10.2:1 Compression Ratio With 118 CC Heads/ 9.7:1 Compression Ratio With 124 CC Heads; 559 Grams; Set Of 8 Pistons And Oil Support Rails
MPN: 212157
With over 60 Years of experience, JE Pistons is the leader in high performance forged pistons. We've built a reputation that the competition can only follow. JE has a history of manufacturing the highest quality pistons and components that professional engine builders, race teams, and high performance enthusiasts trust and rely on. JE's position at the forefront of performance piston manufacturing has been a result of continuous research and development of unique materials, piston designs and technologies. Utilizing State-Of-The-Art CNC machines for manufacturing along with purpose designed forgings, JE is able to maintain exacting specifications on each and every piston and hold tolerances to millionths of an Inch. Also available from JE is industry leading processes like Ultra Crown, a Digital Three Dimensional piston crown machining process and Finite Element Analysis. JE is the only performance piston manufacturer to earn the QS-9000 quality standard which confirms that JE provides customers the highest standards in quality control. Also have State-Of-The-Art inspection equipment and testing equipment which enables us to constantly bring you, the customer, the very latest in piston design configurations.
Engine Compatibility: Chevy Big Block V8 7.4L 454 Cubic Inch
Piston Type: Dome Top
Dome Volume: 18 Cubic Centimeter
Compression Ratio: 10.7:1 With 112 CC/ 10.2:1 With 118 CC/ 9.7:1 With 124 CC
Oversized: 0.060 Inch
Bore Size (IN): 4-1/4 Inch
Material: Aluminum Alloy
Connecting Rod Material: No Connecting Rod
Wrist Pin Style: Floating
Includes Piston Rings: No
Quantity: Set Of 8
Features
- 4032 Low Expansion High Silicon Aluminum Alloy Heat Treated To SRP Specifications
- CNC Machined Domes With Radiused Valve Reliefs Provide Optimum Flame Travel
- Wall Wrist Pin, Pin Fitting And Double Spiro Locks Included
- Designed To Fit Edelbrock STD Series Heads
- Limited 30 Day Warranty
| Specifications of JE Pistons Piston - 212157 | |
| Bore Size (IN) | 4-1/4 Inch |
| Connecting Rod Material | No Connecting Rod |
| Dome Volume | 18 Cubic Centimeter |
| Engine Compatibility | Chevy Big Block V8 7.4L 454 Cubic Inch |
| Includes Piston Rings | No |
| Material | Aluminum Alloy |
| Oversized | 0.060 Inch |
| Piston Type | Dome Top |
| Quantity | Set Of 8 |
| Wrist Pin Style | Floating |
1900-1900 Chevrolet Big Block 1965-1990 Gen IV
1900 Chevrolet Big Block 1965-1990 Gen IV
1900-1900 Chevrolet Big Block 1991-1995 Gen V
1900 Chevrolet Big Block 1991-1995 Gen V
