Grid Wheel GD03 - 18 x 9 Black With Natural Accents - GD03180906451078
Backspacing
5.39
Basic Design
15 Spoke
Bolt Pattern Inch
Not Applicable
Bolt Pattern Millimeter
Not Applicable
Center Bore
78.10
Center Cap
See Replacement Items
Center Cap Design
Grid Logo
Color
Black With Natural Accents
Compatible With TPMS (Tire Pressure Monitoring Sys
Yes
Construction
One Piece Cast
Diameter
18
Share this page
Grid Wheels Wheel
Wheel; GD03; 18 Inch Diameter x 9 Inch Width; 6 x 114.3 Millimeter/ 6 x 4.50 Inch Bolt Pattern; 60 Degree Conical Seat Lug; 10 Millimeter Offset; 5.39 Inch Backspacing; 78.10 Millimeter Center Bore; 15 Spoke; 1 Piece Cast Aluminum Construction; Gloss Black With Milled Accents; 2600 Pound Load Capacity; Compatible With TPMS (Tire Pressure Monitoring System); 38 Inch Max Tire Diameter; With Grid Logo Center Cap; Single
MPN: 3189645M10
Grid off-road wheels are designed for those who prefer to live off the grid. Because when you're off the grid, the possibilities for adventure are endless, which is why grid off-road wheels are strong and durable. whether you're hitting the dunes in Baja, rock crawling in Moab or simply driving to and from work, Grid off-road wheels will more then deliver.
Bolt Pattern Inch: Not Applicable
Bolt Pattern Millimeter: Not Applicable
Diameter: 18
Width: 9
Offset: 10
Backspacing: 5.39
Finish: Painted Gloss With Milled Accents
Color: Black With Natural Accents
Material: Aluminum
Bolt Pattern Inch: 6x4.50
Bolt Pattern Inch: Not Applicable
Bolt Pattern Millimeter: 6x114.3
Bolt Pattern Millimeter: Not Applicable
Lug Nut Seat Type: 60 Degree Conical
Center Cap: See Replacement Items
Center Bore: 78.10
Lug Nut Design: Acorn
Compatible With TPMS (Tire Pressure Monitoring Sys: Yes
Basic Design: 15 Spoke
With Inserts: No
Load Capacity: 2600
Size: 18x9
Max Tire Diameter: 38
Center Cap Design: Grid Logo
Finish Warranty: 1 Year
Structural Warranty: Lifetime
Quantity: Single
Construction: One Piece Cast
With Hub Centric Ring: No
Estimated Install Time (Hours): 0.5
Features
- Gloss Black Finish With Milled Accents
- 1 Piece Cast Aluminum Construction
- Compatible With TPMS (Tire Pressure Monitoring System)
- With Grid Logo Center Cap
- Limited Lifetime Structural Warranty And Limited 1 Year Finish Warranty
Specifications of Grid Wheel GD03 - 18 x 9 Black With Natural Accents - GD03180906451078 | |
Backspacing | 5.39 |
Basic Design | 15 Spoke |
Bolt Pattern Inch | Not Applicable |
Bolt Pattern Millimeter | Not Applicable |
Center Bore | 78.10 |
Center Cap | See Replacement Items |
Center Cap Design | Grid Logo |
Color | Black With Natural Accents |
Compatible With TPMS (Tire Pressure Monitoring Sys | Yes |
Construction | One Piece Cast |
Diameter | 18 |
Estimated Install Time (Hours) | 0.5 |
Finish | Painted Gloss With Milled Accents |
Finish Warranty | 1 Year |
Load Capacity | 2600 |
Lug Nut Design | Acorn |
Lug Nut Seat Type | 60 Degree Conical |
Material | Aluminum |
Max Tire Diameter | 38 |
Offset | 10 |
Quantity | Single |
Size | 18x9 |
Structural Warranty | Lifetime |
Width | 9 |
With Hub Centric Ring | No |
With Inserts | No |
