Grid Wheel GD01 - 24 x 14 Black - GD0124140052B787
Backspacing
4.50
Basic Design
7 Spoke
Bolt Pattern Inch
Not Applicable
Bolt Pattern Millimeter
Not Applicable
Center Bore
87.10
Center Cap
See Replacement Items
Center Cap Design
Grid Logo
Color
Black
Compatible With TPMS (Tire Pressure Monitoring Sys
Yes
Construction
One Piece Cast
Diameter
24
Share this page
Grid Wheel
Wheel; GD01; 24 Inch Diameter x 14 Inch Width; 5 x 127 Millimeter/ 5 x 5.00 Inch/ 5 x 139.7 Millimeter/ 5 x 5.50 Inch Bolt Patterns; 60 Degree Conical Seat Lug; -76 Millimeter Offset; 4.50 Inch Backspacing; 87.10 Millimeter Center Bore; 7 Spoke; 1 Piece Cast Aluminum Construction; Matte Black; 2600 Pound Load Capacity; Compatible With TPMS (Tire Pressure Monitoring System); 40 Inch Max Tire Diameter; With Grid Logo Center Cap; Single
MPN: GD0124140052B787
Bolt Pattern Inch: Not Applicable
Bolt Pattern Millimeter: Not Applicable
Diameter: 24
Width: 14
Offset: -76
Backspacing: 4.50
Finish: Painted Matte
Color: Black
Material: Aluminum
Bolt Pattern Inch: 5x5.00
Bolt Pattern Inch: 5x5.50
Bolt Pattern Millimeter: 5x127
Bolt Pattern Millimeter: 5x139.7
Lug Nut Seat Type: 60 Degree Conical
Center Cap: See Replacement Items
Center Bore: 87.10
Lug Nut Design: Acorn
Compatible With TPMS (Tire Pressure Monitoring Sys: Yes
Basic Design: 7 Spoke
With Inserts: No
Load Capacity: 2600
Size: 24x14
Max Tire Diameter: 40
Center Cap Design: Grid Logo
Finish Warranty: 1 Year
Structural Warranty: Lifetime
Quantity: Single
Construction: One Piece Cast
With Hub Centric Ring: No
Estimated Install Time (Hours): 0.5
Features
- Matte Black Finish
- 1 Piece Cast Aluminum Construction
- Compatible With TPMS (Tire Pressure Monitoring System)
- With Grid Logo Center Cap
- Limited Lifetime Structural Warranty And Limited 1 Year Finish Warranty
Specifications of Grid Wheel GD01 - 24 x 14 Black - GD0124140052B787 | |
Backspacing | 4.50 |
Basic Design | 7 Spoke |
Bolt Pattern Inch | Not Applicable |
Bolt Pattern Millimeter | Not Applicable |
Center Bore | 87.10 |
Center Cap | See Replacement Items |
Center Cap Design | Grid Logo |
Color | Black |
Compatible With TPMS (Tire Pressure Monitoring Sys | Yes |
Construction | One Piece Cast |
Diameter | 24 |
Estimated Install Time (Hours) | 0.5 |
Finish | Painted Matte |
Finish Warranty | 1 Year |
Load Capacity | 2600 |
Lug Nut Design | Acorn |
Lug Nut Seat Type | 60 Degree Conical |
Material | Aluminum |
Max Tire Diameter | 40 |
Offset | -76 |
Quantity | Single |
Size | 24x14 |
Structural Warranty | Lifetime |
Width | 14 |
With Hub Centric Ring | No |
With Inserts | No |
