Edelbrock Cylinder Head 61625
CNC-Machined
Yes
Combustion Chamber Volume (cc)
60 Cubic Centimeter
Condition
New
Engine Compatibility
Ford Small Block V8 5.8L 351C Cubic Inch
Exhaust Port Location
Standard
Exhaust Runner Volume (CC)
90 Cubic Centimeter
Exhaust Valve Diameter (IN)
1.6 Inch
Finish
Satin
Includes Damper Spring
Yes
Includes Guideplates
Yes
Includes Rocker Arm Studs
Yes
Share this page
Edelbrock Cylinder Head
Cylinder Head; Performer RPM; Assembled; Ford 351 Cubic Inch Cleveland Engine; Aluminum; 190 CC Intake Port/ 90 CC Exhaust Port; 60 CC Chamber Volume; 2.05 Inch Intake Valve/ 1.60 Inch Exhaust Valve; 1.55 Inch Spring Diameter; Single; With Guides/ Seats/ Springs For Hydraulic Roller C
MPN: 61625
Performer RPM heads are perfect for street performance, daily drivers, street rods and muscle cars where Seat-Of-The-Pants performance is needed. These heads give great Torque and Horsepower up to 6500 RPM
Condition: New
Engine Compatibility: Ford Small Block V8 5.8L 351C Cubic Inch
Style: Assembled
Finish: Satin
Material: Aluminum
CNC-Machined: Yes
Combustion Chamber Volume (cc): 60 Cubic Centimeter
Intake Runner Volume (CC): 190 Cubic Centimeter
Exhaust Runner Volume (CC): 90 Cubic Centimeter
Port Shape: Rectangular
Intake Port Location: Standard
Exhaust Port Location: Standard
Intake Valve Diameter (IN): 2.05 Inch
Exhaust Valve Diameter (IN): 1.6 Inch
Includes Valves: Yes
Spark Plug Angle: Straight
Rocker Arm Nut Thread Size: 7/16 Inch
Includes Rocker Arm Studs: Yes
Valve Lock Type: 7 Degree
Valve Stem Seal Type: Umbrella
Valve Guide Material: Manganese Bronze
Number Of Springs Per Valve: Single
Valve Seats Machined: Yes
Steam Holes Drilled: No
Machined For O-Ring: No
Includes Guideplates: Yes
Includes Damper Spring: Yes
Features
- Very Streetable 190 Cubic Centimeters Intake Runners
- Compact Charge Combustion Chamber Design
- Intake And Exhaust Ports Based On 2V Design
- Optimized Spark Plug Location Provides Improved Header Clearance
- Match With Edelbrock RPM Air-Gap Manifolds For Optimum Performance
- Limited 1 Year Warranty
| Specifications of Edelbrock Cylinder Head 61625 | |
| CNC-Machined | Yes |
| Combustion Chamber Volume (cc) | 60 Cubic Centimeter |
| Condition | New |
| Engine Compatibility | Ford Small Block V8 5.8L 351C Cubic Inch |
| Exhaust Port Location | Standard |
| Exhaust Runner Volume (CC) | 90 Cubic Centimeter |
| Exhaust Valve Diameter (IN) | 1.6 Inch |
| Finish | Satin |
| Includes Damper Spring | Yes |
| Includes Guideplates | Yes |
| Includes Rocker Arm Studs | Yes |
| Includes Valves | Yes |
| Intake Port Location | Standard |
| Intake Runner Volume (CC) | 190 Cubic Centimeter |
| Intake Valve Diameter (IN) | 2.05 Inch |
| Machined For O-Ring | No |
| Material | Aluminum |
| Number Of Springs Per Valve | Single |
| Port Shape | Rectangular |
| Rocker Arm Nut Thread Size | 7/16 Inch |
| Spark Plug Angle | Straight |
| Steam Holes Drilled | No |
| Style | Assembled |
| Valve Guide Material | Manganese Bronze |
| Valve Lock Type | 7 Degree |
| Valve Seats Machined | Yes |
| Valve Stem Seal Type | Umbrella |
1900-1900 Ford 351C/ 351M/ 400M
1900 Ford 351C/ 351M/ 400M
1900-1900 Ford Small Block 221-351W
1900 Ford Small Block 221-351W
1900-1900 Ford Small Block 347
1900 Ford Small Block 347
