E3 Sparkplugs Ignition Coil E31451

Authorized Dealer
Brand: E3 Spark Plugs
0 reviews
  • Have a product question? Ask us
  • Part Number: E3.1451
  • Part Location: U.S.
  • Availability: *Special Order
  • Delivery: 2 - 3 Weeks
Retail: $125.99
Price: $119.99
You Save: $6.00
Coil Style
E-Coil
Coil Wire Attachment Type
Male/ HEI
Color
Black
Includes Ballast Resistor
No
Includes Coil Wire
No
Includes Mounting Bracket
Yes
Internal Construction
Epoxy
Maximum Voltage
42000 Volt
Primary Resistance
0.02 Ohms
Secondary Resistance
1.38K Ohms
Share this page

E3 Sparkplugs Ignition Coil

Ignition Coil; DiamondFire; E-Coil; 42,000 Maxinum Voltage; 0.02 Ohms Primary Resistance/1.38K Ohms Secondary Resistance/100:1 Turns Ratio; Black; Single

MPN: E31451

Designed multiple motorsports applications, especially oval track and road course, using a 6-series ignition, the DiamondFIRE High Output CD Coil is specially engineered to work with the DiamondFIRE 6CDI capacitive discharge ignition system. The design of the E-core and the use of heavy gauge windings produce a high voltage step up transformer to ensure the fastest possible delivery of the most energy to the spark plug.
Coil Style: E-Coil
Primary Resistance: 0.02 Ohms
Secondary Resistance: 1.38K Ohms
Maximum Voltage: 42000 Volt
Internal Construction: Epoxy
Coil Wire Attachment Type: Male/ HEI
Color: Black
Includes Ballast Resistor: No
Includes Coil Wire: No
Includes Mounting Bracket: Yes

Features

  • Shock And Vibration Resistant
  • High Temperature Epoxy Provides Excellent Thermal Conductivity
  • Extruded Aluminum Housing Provides Maximum Cooling
  • Superior Boot And Terminal Design Protects For Arc Over
  • Limited 5 Year Or 100,000 Mile Warranty
Specifications of E3 Sparkplugs Ignition Coil E31451
Coil Style E-Coil
Coil Wire Attachment Type Male/ HEI
Color Black
Includes Ballast Resistor No
Includes Coil Wire No
Includes Mounting Bracket Yes
Internal Construction Epoxy
Maximum Voltage 42000 Volt
Primary Resistance 0.02 Ohms
Secondary Resistance 1.38K Ohms
