CSF Radiator 3055

Brand: CSF

Have a product question? Ask us
Part Number: 3055
Part Location: U.S.
Availability: 1 In Stock
Delivery: Ships Out in 1 - 2 Business Days
If purchased before 12:00 EDT - estimated delivery by May 27

Retail: $326.54

Price: $310.99

You Save: $15.55

Color

Silver

Core Depth (IN)

1-5/8 Inch

Core Height (IN)

17-1/2 Inch

Core Length (IN)

22-13/16 Inch

Core Material

Aluminum

Core Rows

Finish

Flow Direction

Cross Flow

Includes Fittings

Includes Mounting Hardware

Inlet Hose Location

Top Left

Share this page

CSF Radiator

Radiator; High Performance; Core Dimensions 22-13/16 Inch Length X 17-1/2 Inch Height X 1-5/8 Inch Depth; Two Row; Crossflow; Aluminum; 1-1/2 Inch Top Left Inlet And 1-1/2 Inch Bottom Right Outlet; Without Transmission Cooler

MPN: 3055

CSF manufactures the most advanced and efficient radiator cores in the industry by using innovative tube and fin technologies with industry leading testing methods to maximize airflow and heat dissipation. Unlike a regular oval shape "O" type radiator tube, CSF uses a specially engineered tube in a shape of a "B". These "B-tubes" are carefully formed and then brazed over the seam to seal. CSF is able to use thinner and lighter aluminum material (better cooling efficiency) because this design is actually stronger than normal "O" shape tubes that are welded. The design (inlet in the middle of tube that is seam brazed) increases the heat transfer surface area of the tube by approximately 15 Percent over regular tubes. You get the efficiency of 2 smaller tubes versus 1 large tube within the same space criteria. With "B-tubes" you are able to get "dual liquid laminar flow." CSF uses special "B-Tube" technology in place of traditional "O" type tubes for higher efficiency and added strength. With "B-tubes" you are able to get "dual liquid laminar flow." Each CSF radiator is completed with an industry leading 1 hour, hand polished “Sho-Stopper mirror finish.”

Flow Direction: Cross Flow

Overall Length (IN): OEM

Overall Height (IN): OEM

Overall Depth (IN): OEM

Core Rows: Two

Core Length (IN): 22-13/16 Inch

Core Height (IN): 17-1/2 Inch

Core Depth (IN): 1-5/8 Inch

Core Material: Aluminum

Inlet Hose Location: Top Left

Inlet Size (IN): 1-1/2 Inch

Outlet Hose Location: Bottom Right

Outlet Size (IN): 1-1/2 Inch

Finish: Bare

Color: Silver

Tank Material: Aluminum

With Radiator Cap: No

With Transmission Cooler: No

With Engine Oil Cooler: No

Includes Fittings: No

Includes Mounting Hardware: Yes

Features

Innovative Tube And Fin Technologies With Industry Leading Testing Methods To Maximize Airflow And Heat Dissipation
Specially Engineered Tube In A Shape Of A "B". These "B-Tubes" Are Carefully Formed And Then Brazed Over The Seam To Seal
Thinner And Lighter Aluminum Material (Better Cooling Efficiency) Because This Design Is Actually Stronger Than Normal "O" Shape Tubes That Are Welded
Special "B-Tube" Technology In Place Of Traditional "O" Type Tubes For Higher Efficiency And Added Strength
With "B-Tubes" You Are Able To Get "Dual Liquid Laminar Flow"
Completed With An Industry Leading 1 Hour, Hand Polished “Sho-Stopper Mirror Finish”
Limited 90 Day Warranty

Specifications of CSF Radiator 3055
Color	Silver
Core Depth (IN)	1-5/8 Inch
Core Height (IN)	17-1/2 Inch
Core Length (IN)	22-13/16 Inch
Core Material	Aluminum
Core Rows	Two
Finish	Bare
Flow Direction	Cross Flow
Includes Fittings	No
Includes Mounting Hardware	Yes
Inlet Hose Location	Top Left
Inlet Size (IN)	1-1/2 Inch
Outlet Hose Location	Bottom Right
Outlet Size (IN)	1-1/2 Inch
Overall Depth (IN)	OEM
Overall Height (IN)	OEM
Overall Length (IN)	OEM
Tank Material	Aluminum
With Engine Oil Cooler	No
With Radiator Cap	No
With Transmission Cooler	No
