COMP Cams Valve Spring - 26526-12

Authorized Dealer
Brand: COMP Cams COMP Cams
0 reviews
  • Have a product question? Ask us
  • Part Number: 26526-12
  • Part Location: U.S.
  • Availability: *Special Order
  • Delivery: Up to 2 Weeks
  • If purchased before 12:00 EDT - estimated delivery by July 16
Retail: $417.89
Price: $397.99
You Save: $19.90
Coil Bind Height (IN)
1.1 Inch
Engine Compatibility
Universal
Includes Damper
No
Inside Diameter Of Inner Spring (IN)
0.654 Inch
Inside Diameter Of Outer Spring (IN)
0.92 Inch
Installed Height (IN)
1.835 Inch
Material
Steel
Outside Diameter Of Outer Spring (IN)
1.32 Inch
Quantity
Set Of 12
Spring Rate
505 Pounds Per Inch
Type
Dual
Share this page

COMP Cams Valve Spring

Valve Spring; Universal; 0.654 Inch Inside Diameter/ 1.320 Inch Outside Diameter; Steel; Double Spring; Without Dampener; 505 Pounds Per Inch Spring Rate; 1.835 Inch Installed Height; Set of 12

MPN: 2652612

Ideal for hydraulic roller street/strip applications and some solid flat tappet race applications, the latest Dual Valve Springs from COMP Cams(R) feature a cutting-edge process called Superfinish Race Processing. Most valve springs undergo a single shot peening process to increase durability by driving compressive residual stresses into the wire surface and below. Superfinish Race Processing uses multiple steps of heat treating, peening and polishing to drive the stresses deeper than ever before possible, and smooth out any minute fissures in the spring surface. The proprietary process creates the best possible combination of deep residual compression, enhanced surface compression and surface topography to eliminate stress concentration points. This results in increased lift and durability that extends spring life by at least nine times over comparable springs without the Superfinish. Engineered specifically to maximize the potential of COMP(R) LSR™ Cams for GM LS engines, these springs are also great for many Small Block and Big Block Chevy and Ford street/strip applications. Compared to the original COMP(R) Dual Valve Springs for LSR™ Cams, these new springs will handle more lift while maintaining the same great pitch and diameter design.
Engine Compatibility: Universal
Type: Dual
Material: Steel
Includes Damper: No
Installed Height (IN): 1.835 Inch
Coil Bind Height (IN): 1.1 Inch
Inside Diameter Of Inner Spring (IN): 0.654 Inch
Inside Diameter Of Outer Spring (IN): 0.92 Inch
Outside Diameter Of Outer Spring (IN): 1.32 Inch
Spring Rate: 505 Pounds Per Inch
Quantity: Set Of 12

Features

  • Undergoes A Single Shot Peening Process To Increase Durability
  • Super Finish Race Processing Uses Multiple Steps Of Heat Treating, Peening And Polishing
  • The Proprietary Process Creates The Best Possible Combination Of Deep Residual Compression, Enhanced Surface Compression And Surface Topography To Eliminate Stress Concentration Points
  • Limited 1 Year Warranty
Specifications of COMP Cams Valve Spring - 26526-12
Coil Bind Height (IN) 1.1 Inch
Engine Compatibility Universal
Includes Damper No
Inside Diameter Of Inner Spring (IN) 0.654 Inch
Inside Diameter Of Outer Spring (IN) 0.92 Inch
Installed Height (IN) 1.835 Inch
Material Steel
Outside Diameter Of Outer Spring (IN) 1.32 Inch
Quantity Set Of 12
Spring Rate 505 Pounds Per Inch
Type Dual
