Centerforce DYAD DS 10.4 Clutch Set - 413613000

Authorized Dealer
Brand: Centerforce Centerforce
0 reviews
  • Have a product question? Ask us
  • Part Number: 413613000
  • Part Location: U.S.
  • Availability: *Special Order
  • Delivery: Up to 2 Weeks
  • If purchased before 12:00 EDT - estimated delivery by July 17
Retail: $2,065.34
Price: $1,966.99
You Save: $98.35
Disc Diameter
 10.4 Inch
Disc Friction Face Design
 Segmented Face
Disc Friction Material
 Organic/ Carbon composite
Disc Hub Design
 Sprung Hub
Flywheel Material
 Steel
Includes Alignment Tool
 Yes
Includes Pilot Bearing
 Yes
Includes Throwout Bearing
 No
Input Shaft Size
 1-1/8 Inch X 26 Spline
Number Of Friction Discs
 2 Disc
Pressure Plate Design
 Diaphragm
Share this page

Clutch Set; DYAD Drive System ™; 10.4 Inch Clutch Diameter; 1-1/8 Inch x 26 Spline Input Shaft; Billet Steel Flywheel; With Pressure Plate/ Disc/ Floater/ Flywheel/ Pilot Bearing/ ARP Pressure Plate/ ARP Crank Bolts/ Alignment Tool

MPN: 413613000

The Centerforce ® Dyad DS 10.4 Inch Twin Disc Clutch Has Been Developed For Vehicles Requiring A Holding Capacity Of 500 To 1300 Ft/lbs Of Torque At The Crank. The Pressure Plate Features Our Patented Centrifugal Weight System For Superior Clamp Load Over Stock And Our Patented Ball Bearing Actuated Pressure Plate Providing Light Pedal Effort. The Discs Are Equipped With Organic Segmented Facings Providing Increased Holding Capacity And The Sprung/dampened Drive Disc Provides Smooth Drivability. Dyad Ds Clutches Are Equipped With A Lightened Billet Steel Flywheel Providing Low Inertia Resulting In Quicker Rpms. Components Are Designed Machined And Assembled In The Usa. Dyad Ds Clutches Are Match Balanced And Ready For Installation It Comes With Arp Fasteners.

Pressure Plate Design: Diaphragm
Input Shaft Size: 1-1/8 Inch X 26 Spline
Number Of Friction Discs: 2 Disc
Disc Friction Material: Organic/ Carbon composite
Disc Diameter: 10.4 Inch
Disc Hub Design: Sprung Hub
Pressure Plate Material: Nodular Iron
Flywheel Material: Steel
Includes Throwout Bearing: No
Includes Pilot Bearing: Yes
Disc Friction Face Design: Segmented Face
Torque Holding Capacity: 1300 Feet/ Pound
Includes Alignment Tool: Yes

Features

  • Organic/ Carbon Composite Disc Construction
  • Patented Multi-Disc Design
  • Ball Bearing Design
  • Smooth And Light Pedal Effort
  • Holds 500 To 1300 Feet Per Lbs Of Torque
  • Precision Balanced And Arp Fasteners
  • Come With Spec Card
  • Limited Warranty
Specifications of Centerforce DYAD DS 10.4 Clutch Set - 413613000
Disc Diameter  10.4 Inch
Disc Friction Face Design  Segmented Face
Disc Friction Material  Organic/ Carbon composite
Disc Hub Design  Sprung Hub
Flywheel Material  Steel
Includes Alignment Tool  Yes
Includes Pilot Bearing  Yes
Includes Throwout Bearing  No
Input Shaft Size  1-1/8 Inch X 26 Spline
Number Of Friction Discs  2 Disc
Pressure Plate Design  Diaphragm
Pressure Plate Material  Nodular Iron
Torque Holding Capacity  1300 Feet/ Pound
