Blue Sea Busbar 1991BSS

Brand: Blue Sea Blue Sea
0 reviews
  • Have a product question? Ask us
  • Part Number: 1991-BSS
  • Part Location: U.S.
  • Availability: *Special Order
  • Delivery: Up to 2 Weeks
  • If purchased before 12:00 EDT - estimated delivery by July 18
Retail: $312.89
Price: $297.99
You Save: $14.90
Ampere
1000 Amp
Length (IN)
14.32 Inch
Material
Copper Bus
Number Of Terminals
12
Type
Flat Strip
Voltage Rating
150 Volt
Width (IN)
4.59 Inch
With Insulated Cover
Yes
Share this page

Blue Sea Busbar

Busbar; 12 Stud Terminal/ 16 Screw Terminal; 150 Volts; 1000 Amps; 3/8 Inch-12 Stud; With Insulation Cover; Tin-Plated Copper Bus; Snap On Insulating Cover

MPN: 1991BSS

Complex wiring systems require a single point to consolidate large and small conductors. The PowerBar 1000 offers a 1,000 Ampere busbar with various size studs and screws to connect conductors and fuse blocks.
Type: Flat Strip
Number Of Terminals: 12
Voltage Rating: 150 Volt
Ampere: 1000 Amp
Length (IN): 14.32 Inch
Width (IN): 4.59 Inch
Material: Copper Bus
With Insulated Cover: Yes

Features

  • 1,000 Ampere Busbar For Large Complex Wiring Systems
  • Tin Plated Pure Electrical Copper For Maximum Conductivity
  • Stepped Bus Design Offers Two Elevations For Conductors Which Doubles The Density Of The Wire Loom Compared To Traditional Bus Bars
  • Busbar And Fuse Block Elevations Match Common Fuse Blocks Allowing For Multiple Fuse Block Attachment, Eliminating The Need For Connecting Cables
  • One-Piece Serrated Flange Nuts Ensure Correct And Secure Connections
  • Stainless Steel 8 To 32 Screws With Captive Lock Washers For Securing Smaller Gauge Wires
  • Bi-Directional Busbar End Caps Allow The Ganging Of Additional Busbars
  • Snap On Insulating Cover Meets ABYC And USCG Requirements And Features Label Recess
  • No Supplier Warranty
Specifications of Blue Sea Busbar 1991BSS
Ampere 1000 Amp
Length (IN) 14.32 Inch
Material Copper Bus
Number Of Terminals 12
Type Flat Strip
Voltage Rating 150 Volt
Width (IN) 4.59 Inch
With Insulated Cover Yes
