Blue Sea Busbar 1990BSS
Ampere
1000 Amp
Length (IN)
11.82 Inch
Material
Copper Bus
Number Of Terminals
8
Type
Flat Strip
Voltage Rating
150 Volt
Width (IN)
4.59 Inch
With Insulated Cover
Yes
Share this page
Blue Sea Busbar
Busbar; 8 Stud Terminal/ 16 Screw Terminal; 150 Volts; 1000 Amps; 3/8 Inch-8 Studs; With Insulation Cover; Tin-Plated Copper Bus; Snap On Insulating Cover
MPN: 1990BSS
Complex wiring systems require a single point to consolidate large and small conductors. The PowerBar 1000 offers a 1,000 Ampere busbar with various size studs and screws to connect conductors and fuse blocks.
Type: Flat Strip
Number Of Terminals: 8
Voltage Rating: 150 Volt
Ampere: 1000 Amp
Length (IN): 11.82 Inch
Width (IN): 4.59 Inch
Material: Copper Bus
With Insulated Cover: Yes
Features
- 1,000 Ampere Busbar For Large Complex Wiring Systems
- Tin Plated Pure Electrical Copper For Maximum Conductivity
- Stepped Bus Design Offers Two Elevations For Conductors Which Doubles The Density Of The Wire Loom Compared To Traditional Bus Bars
- Busbar And Fuse Block Elevations Match Common Fuse Blocks Allowing For Multiple Fuse Block Attachment, Eliminating The Need For Connecting Cables
- One-Piece Serrated Flange Nuts Ensure Correct And Secure Connections
- Stainless Steel 8 To 32 Screws With Captive Lock Washers For Securing Smaller Gauge Wires
- Bi-Directional Busbar End Caps Allow The Ganging Of Additional Busbars
- Snap On Insulating Cover Meets ABYC And USCG Requirements And Features Label Recess
- No Supplier Warranty
| Specifications of Blue Sea Busbar 1990BSS | |
| Ampere | 1000 Amp |
| Length (IN) | 11.82 Inch |
| Material | Copper Bus |
| Number Of Terminals | 8 |
| Type | Flat Strip |
| Voltage Rating | 150 Volt |
| Width (IN) | 4.59 Inch |
| With Insulated Cover | Yes |
