Bilstein B8 8112 Series Shock Absorber - 41-284674

Name: Bilstein B8 8112 Series Shock Absorber - 41-284674
Brand: Bilstein
SKU: 41-284674
Price: 1289.99 USD
Availability: InStock

Authorized Dealer

Brand:

Bilstein

0 reviews

Have a product question? Ask us
Part Number: 41-284674
Part Location: U.S.
Availability: *Special Order
Delivery: Up to 2 Weeks
If purchased before 12:00 EDT - estimated delivery by July 25

Retail: $1,354.49

Price: $1,289.99

You Save: $64.50

Adjustable Valving

Yes

Body Color

Black

Compressed Length (IN)

19.02 Inch

Estimated Install Time (Hours)

0.5

Extended Length (IN)

23.78 Inch

Includes Boot

Includes Dust Shield

Includes Hardware

Yes

Internal Design

Monotube

Lower Mounting Style

Cross Pin

Quantity

Single

Share this page

Shock Absorber; B8 8112 (ZoneControl CR); Nitrogen Gas Charged; With Reservoir; Limited 2 Years Warranty; Non Adjustable Valving; Single

MPN: 41-284674

Bilstein B8 8112 (ZoneControl) CR suspension kits are a direct fit, position sensitive coilover designed for light trucks and SUV’s. ZoneControl CR is a revolutionary technology delivering position sensitive damping. The system incorporates a triple piston design, offering 3 stages of compression valving and 2 stages of rebound valving. The coilover module utilizes a threaded spring seat for ride height adjustability ranging from 0 to 3.8 Inch (depending on application). The coilover is supplied with a remote reservoir for increased cooling and an accompanied, bolt-on anodized reservoir chassis mount. BILSTEIN B8 8112 (ZoneControl) CR position sensitive coilovers will offer unparalleled ride comfort during every day driving combined with maximum control over large suspension inputs.

Type: Nitrogen Gas Charged

With Coil Spring: Yes

Internal Design: Monotube

Adjustable Valving: Yes

Extended Length (IN): 23.78 Inch

Compressed Length (IN): 19.02 Inch

Upper Mounting Style: Stud

Lower Mounting Style: Cross Pin

Body Color: Black

Quantity: Single

Valving Type: 3 Stage Of Compression Valving And 2 Stage Of Rebound Valving

With Reservoir: Yes

Includes Dust Shield: No

Includes Hardware: Yes

Includes Boot: No

Estimated Install Time (Hours): 0.5

Features

Aluminum Components With Zinc Plated Shock Bodies Will Resist Harsh Off-Road Elements
High Quality Chrome 5/8 Inch Heim Joint Mounting With Rubber Sealed Misalignment Spacers Offer The Most Durable, Load Bearing Mount Solution
Position Sensitive Damping With 3 Compression Zones And 2 Rebound Zones, Controlled By 3 Independent Pistons
Secondary Rebound Stop Will Dissipate Spring Energy And Stabilize The Suspension Directly Following A Large Compression Event
The Internal Rebound Stop Will Also Eliminate Harsh Top-Out Events And The Need For An External Limit Strap
60 Millimeter Remote Reservoir For Increased Oil Capacity And Cooling
Provides Superior Bottom Out Control Through A 2-Stage, Telescoping Internal Compression Stop
Eliminates The Need For An External Hydraulic Bump Stop
Triple Piston Design Delivers Comfort During Every Day Driving Conditions And Maximum Control Under Large Suspension Inputs
Limited 2 Year Warranty

Specifications of Bilstein B8 8112 Series Shock Absorber - 41-284674
Adjustable Valving	Yes
Body Color	Black
Compressed Length (IN)	19.02 Inch
Estimated Install Time (Hours)	0.5
Extended Length (IN)	23.78 Inch
Includes Boot	No
Includes Dust Shield	No
Includes Hardware	Yes
Internal Design	Monotube
Lower Mounting Style	Cross Pin
Quantity	Single
Type	Nitrogen Gas Charged
Upper Mounting Style	Stud
Valving Type	3 Stage Of Compression Valving And 2 Stage Of Rebound Valving
With Coil Spring	Yes
With Reservoir	Yes
