Bilstein B8 8112 Series Shock Absorber - 41-284568

Authorized Dealer
Brand: Bilstein Bilstein
0 reviews
  • Have a product question? Ask us
  • Part Number: 41-284568
  • Part Location: U.S.
  • Availability: *Special Order
  • Delivery: Up to 2 Weeks
  • If purchased before 12:00 EDT - estimated delivery by July 25
Retail: $1,452.14
Price: $1,382.99
You Save: $69.15
Adjustable Valving
 No
Body Color
 Silver
Body Material
 Steel
Compressed Length (IN)
 17.99 Inch
Estimated Install Time (Hours)
 0.5
Extended Length (IN)
 22.8 Inch
Includes Boot
 No
Includes Dust Shield
 No
Includes Hardware
 Yes
Internal Design
 Monotube
Lower Mounting Style
 Eyelet
Share this page

Shock Absorber; B8 8112 (ZoneControl CR); Nitrogen Gas Charged; With Reservoir; Limited 2 Year Warranty; Non Adjustable Valving; Extended Height 22.8 Inch/ Collapsed Height 17.99 Inch; Single; With Optional Heavy Load Springs

MPN: 41-284568

Bilstein B8 8112 (ZoneControl) CR suspension kits are a direct fit, position sensitive coilover designed for light trucks and SUV’s. ZoneControl CR is a revolutionary technology delivering position sensitive damping. The system incorporates a triple piston design, offering 3 stages of compression valving and 2 stages of rebound valving. The coilover module utilizes a threaded spring seat for ride height adjustability ranging from 0 to 3.8 Inch (depending on application). The coilover is supplied with a remote reservoir for increased cooling and an accompanied, bolt-on anodized reservoir chassis mount. BILSTEIN B8 8112 (ZoneControl) CR position sensitive coilovers will offer unparalleled ride comfort during every day driving combined with maximum control over large suspension inputs.

Type: Nitrogen Gas Charged
With Coil Spring: Yes
Internal Design: Monotube
Adjustable Valving: No
Extended Length (IN): 22.8 Inch
Compressed Length (IN): 17.99 Inch
Upper Mounting Style: Cross Pin
Lower Mounting Style: Eyelet
Body Color: Silver
Quantity: Single
Valving Type: Non Adjustable Valving
Ride Height Adjustable: Yes
Rod Material: Steel
Body Material: Steel
With Reservoir: Yes
Includes Dust Shield: No
Includes Hardware: Yes
Includes Boot: No
Estimated Install Time (Hours): 0.5

Features

  • Triple Piston Design Delivers Comfort During Every Day Driving Conditions And Maximum Control Under Large Suspension Inputs
  • Adjustable Threaded Spring Seat Allows For Fine-Tuned Ride Height
  • 60 Millimeter Remote Reservoir For Increased Oil Capacity And Cooling
  • Vehicle Specific Design And Tuning Provides The Ultimate Driving Experience
  • Aerospace Quality Components Are Vehicle Specific To Optimize Wheel Travel And Clearance
  • High Quality Chrome 5/8 Inch Heim Joint Mounting With Rubber Sealed Misalignment Spacers Offer The Most Durable, Load Bearing Mount Solution
  • Aluminum Components With Zinc Plated Shock Bodies Will Resist Harsh Off-Road Elements
  • Spring Is Pre-Loaded To The Factory Recommended Ride Height
  • Coilover Supplied As A Complete Module For Easy Installation
  • Limited 2 Year Warranty
Specifications of Bilstein B8 8112 Series Shock Absorber - 41-284568
Adjustable Valving  No
Body Color  Silver
Body Material  Steel
Compressed Length (IN)  17.99 Inch
Estimated Install Time (Hours)  0.5
Extended Length (IN)  22.8 Inch
Includes Boot  No
Includes Dust Shield  No
Includes Hardware  Yes
Internal Design  Monotube
Lower Mounting Style  Eyelet
Quantity  Single
Ride Height Adjustable  Yes
Rod Material  Steel
Type  Nitrogen Gas Charged
Upper Mounting Style  Cross Pin
Valving Type  Non Adjustable Valving
With Coil Spring  Yes
With Reservoir  Yes

2010 Toyota 4Runner
2011 Toyota 4Runner
2012 Toyota 4Runner
2013 Toyota 4Runner
2014 Toyota 4Runner
2015 Toyota 4Runner
2016 Toyota 4Runner
2017 Toyota 4Runner
2018 Toyota 4Runner
2019 Toyota 4Runner
2020 Toyota 4Runner
2021 Toyota 4Runner

2010 Toyota FJ Cruiser
2011 Toyota FJ Cruiser
2012 Toyota FJ Cruiser
2013 Toyota FJ Cruiser
2014 Toyota FJ Cruiser
