Bilstein B8 8100 BP Series Shock Absorber - 25-316230

Authorized Dealer
Brand: Bilstein Bilstein
0 reviews
  • Have a product question? Ask us
  • Part Number: 25-316230
  • Part Location: U.S.
  • Availability: *Special Order
  • Delivery: Up to 2 Weeks
  • If purchased before 12:00 EDT - estimated delivery by July 25
Retail: $1,452.14
Price: $1,382.99
You Save: $69.15
Adjustable Valving
 Yes
Body Color
 Silver
Compressed Length (IN)
 15.69 Inch
Estimated Install Time (Hours)
 0.5
Extended Length (IN)
 25.82 Inch
Includes Boot
 No
Includes Dust Shield
 No
Includes Hardware
 Yes
Internal Design
 Twin Tube
Lower Mounting Style
 Eyelet
Quantity
 Single
Share this page

Shock Absorber; B8 8100 BP; Direct Fit; Adjustable Bypass Design; Limited Lifetime Warranty; Double Adjustable Compression And Rebound; 15.69 Inch Compressed Lenght; 25.82 Inch Extended Length; Without Shock Boot; Zinc Plated; Single

MPN: 25-316230

Bypass shock absorbers offer the most compliant ride in all conditions and provide maximum bottom out control when the road gets rough. Utilizing an adjustable external bypass shock is the easiest and most effective way to tune your suspension for ultimate performance.

With Coil Spring: No
Internal Design: Twin Tube
Adjustable Valving: Yes
Extended Length (IN): 25.82 Inch
Compressed Length (IN): 15.69 Inch
Upper Mounting Style: Stud
Lower Mounting Style: Eyelet
Body Color: Silver
Quantity: Single
Rod Diameter (IN): 0.7 Inch
Rod Material: Aluminum
With Reservoir: Yes
Includes Dust Shield: No
Includes Hardware: Yes
Includes Boot: No
Estimated Install Time (Hours): 0.5

Features

  • The Bump Zone, Located Above The Compression Bypass Tube, Increases Bottoming Control And Eliminates The Need For A Hydraulic Bump Stop
  • Dual Tube External Bypass Offers Position Sensitive Damping With Independent Adjustment For Rebound And Compression
  • Incremental Flow Adjuster Offers Finite And Incremental Changes In Damping Force For Precise Adjustments
  • Bottom Port Reservoir Hose Provides Increased Bottom Out Control During The Compression Cycle
  • Billet Rod End With Vulcanized Mounts For An Exact OE Fit And Long-Term Durability
  • Vehicle Specific Tuning With The Ability To Make A Wide Range Of Adjustments
  • 60 Millimeter Large Bore Hard Anodized Aluminum Piston Offers A Greater Range Of Damping Control And Delivers Exceptional Long-Term Durability
  • Direct Fit For Easy Installation
  • 18 Millimeter Piston Rod Provides Brute Tensile Strength And Reduces Internal Gas Force Ramp-Up Providing A Smoother Ride
  • Limited 2 Year Warranty
Specifications of Bilstein B8 8100 BP Series Shock Absorber - 25-316230
Adjustable Valving  Yes
Body Color  Silver
Compressed Length (IN)  15.69 Inch
Estimated Install Time (Hours)  0.5
Extended Length (IN)  25.82 Inch
Includes Boot  No
Includes Dust Shield  No
Includes Hardware  Yes
Internal Design  Twin Tube
Lower Mounting Style  Eyelet
Quantity  Single
Rod Diameter (IN)  0.7 Inch
Rod Material  Aluminum
Upper Mounting Style  Stud
With Coil Spring  No
With Reservoir  Yes

2019 Ram 1500- New Model
2020 Ram 1500- New Model
2021 Ram 1500- New Model
2022 Ram 1500- New Model
