ARB Shock Absorber - N190
Adjustable Valving
No
Body Color
Yellow
Body Material
Steel
Compressed Length (IN)
15.51 Inch
Estimated Install Time (Hours)
0.5
Extended Length (IN)
25.9 Inch
Includes Boot
Yes
Includes Dust Shield
No
Includes Hardware
No
Internal Design
Twin Tube
Lower Mounting Style
Eyelet
Share this page
Shock Absorber; Nitrocharger; Nitrogen Gas Charged; 3 Year 36,000 Mile Warranty; Non Adjustable; With Shock Absorber Boot; Single
MPN: N190
Nitrocharger 4×4 shock absorbers were specifically designed with Australia’s unique driving conditions in mind, where vehicles are often heavily loaded, fitted with accessories and driven on harsh, Outback roads for prolonged periods. Old Man Emu engineers specialize in nothing else but 4WD suspension systems, and it’s this experience in setting the most appropriate valving that really differentiates the Nitrocharger from its competitors. In many cases, several shock absorber applications will be listed for one vehicle to ensure the proper match regardless of spring selection, accessory fitment or load carrying requirements. And while OME Nitrochargers will improve overall performance when fitted with standard springs, more substantial benefits can be achieved with fitted in conjunction with Old Man Emu springs, for a complete, integrated 4WD suspension system.Type: Nitrogen Gas Charged
With Coil Spring: No
Internal Design: Twin Tube
Adjustable Valving: No
Extended Length (IN): 25.9 Inch
Compressed Length (IN): 15.51 Inch
Upper Mounting Style: Eyelet
Lower Mounting Style: Eyelet
Body Color: Yellow
Quantity: Single
Rod Diameter (IN): 0.7 Inch
Valving Type: 7 Stage Compression Valving
Rod Material: Steel
Body Material: Steel
With Reservoir: No
Includes Dust Shield: No
Includes Hardware: No
Includes Boot: Yes
Estimated Install Time (Hours): 0.5
Features
- Tough Urethane Bushes For Extended Life. A Multi-Stage Compression Valve Incorporates A Wider Range Of Valve Performance Resulting In Improved Vehicle Control And Ride Suppleness
- Unique Triple Lip Check Valve Seal Offers Excellent Gas And Oil Retention. Supplementary Top And Bottom Welds Give Added Strength And Safety
- The Balanced, 1.4 Inch Teflon Banded Rebound Piston Delivers Outstanding Valve Control Resulting In Better Ride And Handling
- The Equalized Pressure System Is Delivered Through Multi-Stage Valving, Eliminates Oil Starvation At High Speed And Greatly Reduces Heat And Pressure Build Up
- Super Strong .71 Inch Hard Chromed Piston Rod. The Eccentric Sliding Intake Valve Increases Valving Response Time And Reduces Operating Noise
- Low Pressure Nitrogen Gas For Optimum Performance
- Tough Twin Tube Design With Super Strong .6 Inch Thick Reserve Tube Protects Vital Internal Components
- Limited 3 Year Or Unlimited Kilometer Warranty
Specifications of ARB Shock Absorber - N190 | |
Adjustable Valving | No |
Body Color | Yellow |
Body Material | Steel |
Compressed Length (IN) | 15.51 Inch |
Estimated Install Time (Hours) | 0.5 |
Extended Length (IN) | 25.9 Inch |
Includes Boot | Yes |
Includes Dust Shield | No |
Includes Hardware | No |
Internal Design | Twin Tube |
Lower Mounting Style | Eyelet |
Quantity | Single |
Rod Diameter (IN) | 0.7 Inch |
Rod Material | Steel |
Type | Nitrogen Gas Charged |
Upper Mounting Style | Eyelet |
Valving Type | 7 Stage Compression Valving |
With Coil Spring | No |
With Reservoir | No |
2006 Jeep Commander
2007 Jeep Commander
2008 Jeep Commander
2009 Jeep Commander
2010 Jeep Commander
2007 Jeep Commander
2008 Jeep Commander
2009 Jeep Commander
2010 Jeep Commander
2005 Jeep Grand Cherokee
2006 Jeep Grand Cherokee
2007 Jeep Grand Cherokee
2008 Jeep Grand Cherokee
2009 Jeep Grand Cherokee
2010 Jeep Grand Cherokee
2006 Jeep Grand Cherokee
2007 Jeep Grand Cherokee
2008 Jeep Grand Cherokee
2009 Jeep Grand Cherokee
2010 Jeep Grand Cherokee
