Advanced Clutch Disc Single 4 Paddle - 4228218

Brand: Advanced Clutch Advanced Clutch
  • Have a product question? Ask us
  • Part Number: 4228218
  • Part Location: U.S.
  • Availability: *Special Order
  • Delivery: 2 - 3 Weeks
Retail: $227.84
Price: $216.99
You Save: $10.85
Diameter (IN)
 8.98 Inch
Friction Face Design
 Single 4 Paddle
Friction Material
 Ceramic
Friction Pad Mounting Type
 Riveted
Hub Design
 Sprung Hub
Input Shaft Diameter (IN)
 1 Inch
Input Spline Quantity
 24
Plate Material
 Steel
Share this page

Clutch Disc; Race; Single Disc; 4 Paddle Design; 8.98 Inch Diameter; 1 Inch x 24 Spline Input Shaft; Sprung Hub; Ceramic Friction Material; Steel Plate Material

MPN: 4228218

ACT Xtreme race discs are available in 4 or 6 pad solid hub designs that are highly durable and resistant to heat. ACT recommends 6 pad ACT Xtreme race discs for longer clutch size to absorb more heat and for smoother engagement. The 4 pad ACT Xtreme race discs engage harsher, shift faster, and are well suited for the smaller disc sizes in smaller engines

Friction Face Design: Single 4 Paddle
Diameter (IN): 8.98 Inch
Hub Design: Sprung Hub
Input Shaft Diameter (IN): 1 Inch
Input Spline Quantity: 24
Friction Material: Ceramic
Plate Material: Steel
Friction Pad Mounting Type: Riveted

Features

  • Lightweight Rigid Design For Quicker Shifts And Smooth, Trouble Free Service
  • Spring Center Construction Properly Dampens Torsional Vibrations For Quieter Operation
  • Center Section Resists Failure Even Under Harsh Conditions
  • Chrome Moly Hub Is Heat Treated For Strength And Durability
  • Heat Treated Steel Drive Plate
  • High Quality Ceramic Friction Material Which Produces 28 Percent More Friction And Torque Capacity Over Organic Materials
  • Limited 1 Year Warranty
Specifications of Advanced Clutch Disc Single 4 Paddle - 4228218
Diameter (IN)  8.98 Inch
Friction Face Design  Single 4 Paddle
Friction Material  Ceramic
Friction Pad Mounting Type  Riveted
Hub Design  Sprung Hub
Input Shaft Diameter (IN)  1 Inch
Input Spline Quantity  24
Plate Material  Steel

2006 Saab 9-2X

2006 Subaru Impreza
2007 Subaru Impreza
2008 Subaru Impreza
2009 Subaru Impreza
2010 Subaru Impreza
2011 Subaru Impreza

2005 Subaru Legacy
2006 Subaru Legacy

2015 Subaru WRX
2016 Subaru WRX
2017 Subaru WRX
2018 Subaru WRX
2019 Subaru WRX
2020 Subaru WRX
2021 Subaru WRX
